244

Internal diffuser and special lens pattern

for optimal 360° signalling effect

• 94 mm cubic-design LED steady/flashing beacon with

built-in buzzer indicator

• Max. 80 dB (A) sound pressure

• High degree of protection IP 65 & impact resistance IK09

• UV-stabilised material

• Steady and flashing light, can be switched externally

• Beacon with good frontal/lateral signalling effect

• 30 cd luminous intensity

• For industrial and general applications

Housing

94 mm (square), Polycarbonate red, piezo buzzer black

Lens

Polycarbonate, ribbed inside orange, red, clear, blue,

green or yellow

Type of mounting

any, any

Connection technology Screw/plug-in terminal up to 2,5 mm²

Beacon type

Steady beacon or Flashing beacon

Light source

16 LEDs

Luminous intensity

30 Cd

Strobe/flash frequency 1,4 Hz

technical data

Tone

2 Tones, 2 Tones can be switched externally,

Steady tone or Pulsing tone

Volume

80 dB

Tone frequency

3.500 Hz

Duty cycle

100 %

Service life

Light source: 50.000 h

Operating temperature -30 °C / +60 °C

Degree of protection

IP65

Impact resistance

IK09

Weight

300 g

qSS

Q-Series

LED steady/flashing beacon with buzzer indicator

e lectron i c So u n d e r – b eacon com b i nati on
