BradyID.com/i5100 • 1-888-272-3946

7

BradyPrinter i5100 printers and accessories

Printers

Printers ship ready to use with 1 auto-detect media roll holder, 1 ribbon takeup spindle, power cord, USB cable,

user manual, user license for Brady Workstation PWID Software suite, and a CD that contains drivers, user manual

in 24 languages and configuration manual.

Catalog #

Description

Details

149452

i5100 Industrial Label Printer,

Standard Version, 300 dpi

Prints on labels, tags and select continuous media wound on rolls or fanfolded. Media is torn off after printing

using tear bar that is standard on printer.

149455

i5100 Industrial Label Printer,

Standard Version, 600 dpi

Prints on labels, tags and select continuous media wound on rolls or fanfolded. Media is torn off after printing

using tear bar that is standard on printer. 600 dpi head is ideal for smaller fonts, intricate graphics and bar

coding, including 2D codes.

149453

i5100 Industrial Label Printer,

Auto Cutter Version, 300 dpi

In addition to the capabilities of standard model, this configuration has a built-in auto cutter and tear bar to allow

for tear-off or complete cut-through printing. Cutting is limited to cuttable materials at down-web label lengths of

12 mm or greater.

149456

i5100 Industrial Label Printer,

Auto Cutter Version, 600 dpi

In addition to the capabilities of standard model, this configuration has a built-in auto cutter and tear bar to allow

for tear-off or complete cut-through printing. Cutting is limited to cuttable materials at down-web label lengths of

12 mm or greater. 600 dpi head is ideal for smaller fonts, intricate graphics and bar coding, including 2D codes.

Accessories

Catalog #

Description

Details

149470

Spare i5100/IP Media Roll

Holder, Auto-detect

Holds 3 in. open core media rolls and auto-detects Brady IP-enabled media rolls. Separates and slides back together

easily for fast self-centering installation of media roll. Also fits Brady IP-model printers.

149562

Spare i5100/IP Ribbon

Takeup Spindle

Features flexible green tab for faster ribbon threading and a quick-release lever for removing used ribbon from spindle.

When using this spindle, no separate cardboard ribbon core is needed. Also fits Brady IP-model printers.

149131

USB WLAN Stick

2.4 GHz 802.11b/g/n + 5 GHz a/n/ac with rod antenna for extended reach.

149080

USB Bluetooth Adapter

USB Bluetooth adapter.

149563

RS232 Cable

Connecting cable RS232 C 9/9 pin, 3 m length.

Catalog #

Description

Details

149471

Print Roller 120 mm

For media up to 119 mm wide. Use ribbon that is at least 121 mm wide.

149598

Print Roller 80 mm

For media up to 79 mm wide. Use ribbon that is at least 81 mm wide.

149473

Print Roller 50 mm

For media up to 49 mm wide. Use ribbon that is at least 51 mm wide.

149472

Print Roller 25 mm

For media up to 24 mm wide. Use ribbon that is at least 26 mm wide.

PCK-6

IPA Printer Cleaning Swabs Pre-soaked in IPA, lint-free synthetic cleaning swabs for cleaning rollers, print heads and sensors. Package of 50

individually wrapped swabs.

Replaceable print rollers

Minimize wear on the print head by pairing narrow rollers with narrow media — always be sure the roller is wider than

the label media and the ribbon is wider than the roller.
