2 / 16 page  –2– REV. F AD8009–SPECIFICATIONS (@ T A = 25 C, VS = 5 V, RL = 100 ; for R Package: RF = 301 for G = +1, +2, RF = 200 for G = +10; for RT Package: RF = 332 for G = +1, RF = 226 for G = +2 and RF = 191 for G = +10, unless otherwise noted.) AD8009AR/JRT Model Conditions Min Typ Max Unit DYNAMIC PERFORMANCE –3 dB Small Signal Bandwidth, VO = 0.2 V p-p R Package G = +1, RF = 301 Ω 1,000 MHz RT Package G = +1, RF = 332 Ω 845 MHz G = +2 480 700 MHz G = +10 300 350 MHz Large Signal Bandwidth, VO = 2 V p-p G = +2 390 440 MHz G = +10 235 320 MHz Gain Flatness 0.1 dB, VO = 0.2 V p-p G = +2, RL = 150 Ω 45 75 MHz Slew Rate G = +2, RL = 150 Ω, 4 V Step 4,500 5,500 V/ µs Settling Time to 0.1% G = +2, RL = 150 Ω, 2 V Step 10 ns G = +10, 2 V Step 25 ns Rise and Fall Time G = +2, RL = 150 Ω, 4 V Step 0.725 ns HARMONIC/NOISE PERFORMANCE Second Harmonic G = +2, VO = 2 V p-p 10 MHz –73 dBc 20 MHz –66 dBc 70 MHz –56 dBc Third Harmonic 10 MHz –77 dBc 20 MHz –75 dBc 70 MHz –58 dBc Third Order Intercept (3IP) 70 MHz 26 dBm W.R.T. Output, G = +10 150 MHz 18 dBm 250 MHz 12 dBm Input Voltage Noise f = 10 MHz 1.9 nV/ √Hz Input Current Noise f = 10 MHz, +In 46 pA/ √Hz f = 10 MHz, –In 41 pA/ √Hz Differential Gain Error NTSC, G = +2, RL = 150 Ω 0.01 0.03 % NTSC, G = +2, RL = 37.5 Ω 0.02 0.05 % Differential Phase Error NTSC, G = +2, RL = 150 Ω 0.01 0.03 Degrees NTSC, G = +2, RL = 37.5 Ω 0.04 0.08 Degrees DC PERFORMANCE Input Offset Voltage 25 mV TMIN to TMAX 7mV Offset Voltage Drift 4 µV/°C –Input Bias Current 50 150 ±µA TMIN to TMAX 75 ±µA +Input Bias Voltage 50 150 ±µA TMIN to TMAX 75 ±µA Open-Loop Transresistance 90 250 k Ω TMIN to TMAX 170 k Ω INPUT CHARACTERISTICS Input Resistance +Input 110 k Ω –Input 8 Ω Input Capacitance +Input 2.6 pF Input Common-Mode Voltage Range 3.8 ±V Common-Mode Rejection Ratio VCM = ±2.5 50 52 dB OUTPUT CHARACTERISTICS Output Voltage Swing ±3.7 ±3.8 V Output Current RL = 10 Ω, PD Package = 0.7 W 150 175 mA Short-Circuit Current 330 mA POWER SUPPLY Operating Range +5 ±6V Quiescent Current 14 16 mA TMIN to TMAX 18 mA Power Supply Rejection Ratio VS = ±4 V to ±6 V 64 70 dB Specifications subject to change without notice. |
|
|
