Current

Rating

(A)

Poles

A

B

Pg

∅

∅

16

153

77

16

158

85

166

93

21

32

183

98

188

105

3P +N +

3P +

2P +

3P +N +

3P +

2P +

PEW16/32_pv Series

Mains Plugs

Page 1

22/06/06 V1.0

Features:

• In compliance with EN 60309-1 and EN 60309-2 standards.

• Enclosure, insert and spring lid in insulating, thermoplastic,

self-extinguishing material.

• Cable anchoring collar incorporated in the insert.

• Complete with entry gland.

• RAL 7035 grey enclosure, spring lid with locking ring and

gasket colour coded according to the operating voltage, entry

with cable gland.

• Cable anchorage with retained screws.

Dimensions : Millimetres

Description

Part Number

Coupler 16A 240V

PEW1663PVB

Coupler 16A 415V

PEW1665PVB

Plug 415V 32A

PEW3265PVB

Coupler 240V 32A

PEW3263PVA

Coupler 415V 32A

PEW3265PVA

Part Number Table
