The LED module itself and all its components must not be

mechanically stressed.

Assembly must not damage or destroy conducting paths on

the circuit board.

The mounting of the module is carried out by attaching

it to the mounting holes. Metal mounting screws must be

insulated with synthetic washers to prevent circuit board

damage and possible short circuiting.

To avoid mechanical damage to the connecting cables,

the boards should be attached securely to the intended

substrate. Heavy vibration should be avoided.

Observe correct polarity! Depending on the product,

incorrect polarity will lead to emission of red or no light. The

module can be destroyed!

Pay attention to standard ESD precautions when installing

the PowerFlex.

SAFETY INFORMATION

The PowerFlex, as manufactured, has no conformal

coating and therefore offers no inherent protection against

corrosion. Damage by corrosion will not be accepted as

a materials defect claim. It is the user’s responsibility to

provide suitable protection against corrosive agents such as

moisture and condensation and other harmful elements.

For outdoor usage, a housing is definitely required to

protect the board against environmental influences. The

design of the housing must correspond to the IP standards

in the application. It is also the responsibility of the user to

ensure any housings or modifications keep the Tc junction

temperature to within stated ranges.

To also ease the luminaire/installation approval, electronic

control gear for LED or LED modules should carry the CE

mark and be ENEC certified. In Europe the declarations

of conformity must include the following standards: CE: EC

61374-2-13, EN 55015, IEC 61547 and IEC 61000-3-2 -

ENEC: 61374-2-13 and IEC/EN 62384.

The evaluation of eye safety occurs according to the

standard IEC 62471:2006 (“photobiological safety of

lamps and lamp systems”). Within the risk grouping system

of this CIE standard, the LED specified in this data sheet

falls into the class “moderate risk” (exposure time 0.25s).

Under real circumstances (for exposure time, eye pupils,

observation distance), it is assumed that no endangerment

to the eye exists from these devices. As a matter of principle,

however, it should be mentioned that intense light sources

have a high secondary exposure potential due to their

blinding effect. As is also true when viewing other bright

light sources (e.g. headlights), temporary reduction in

visual acuity and afterimages can occur, leading to

irritation, annoyance, visual impairment and even accidents,

depending on the situation.
