RTQ-B1221 | ZoneControl

MULTITASK PHOTOELECTRIC SENSORS

Switching output

PNP, NPN 4)

Switching mode

Light/dark switching 4)

Signal voltage PNP HIGH/LOW

Approx. VS – 0.5 V / 0 V

Signal voltage NPN HIGH/LOW

Approx. VS / < 2.0 V

Output current Imax.

≤ 100 mA

Response time

2 ms

Switching frequency

250 Hz

Connection type

Male connector M12, 4-pin

Circuit protection

A 5)

C 6)

D 7)

Protection class

III

Weight

175 g

Housing material

Plastic, ABS

Enclosure rating

IP67

Shock and vibration resistance

According to IEC 68

Ambient operating temperature

–40 °C ... +60 °C

Ambient temperature, storage

–40 °C ... +75 °C

UL File No.

NRKH.E189383 & NRKH7.E189383

1) Limit values.

2) May not exceed or fall below Uv tolerances.

3) Without load and valve deenergized.

4) Selectable via light/dark rotary switch.

5) A = VS connections reverse-polarity protected.

6) C = interference suppression.

7) D = outputs overcurrent and short-circuit protected.

Safety-related parameters

MTTFD

1,009 years

DCavg

0 %

Classifications

ECLASS 5.0

27270904

ECLASS 5.1.4

27270904

ECLASS 6.0

27270904

ECLASS 6.2

27270904

ECLASS 7.0

27270904

ECLASS 8.0

27270904

ECLASS 8.1

27270904

ECLASS 9.0

27270904

ECLASS 10.0

27270904

ECLASS 11.0

27270904

ECLASS 12.0

27270903

ETIM 5.0

EC002719

2024-04-03 12:15:58 | Product data sheet

Subject to change without notice
