ECF504-R5E datasheet(1/1 Pages) L-COM

部件名	ECF504-R5E

功能描述	CPLR RJ45 F/F CAT5E RT ANGLE

PDF	1 Pages

Scroll/Zoom	100%

制造商	L-COM [Infinite Electronics International, Inc.]

网页	https://www.l-com.com/

标志

1 / 1 page

FLANGE MOUNTED KEYSTONE ADAPTOR

KIT SHOWN FULLY ASSEMBLED FOR CLARITY

(KIT IS SHIPPED UN-ASSEMBLED)

CAT 5E RIGHT ANGLE RJ45 COUPLER

(L-COM P/N TDG1026KC-R5E

WITHOUT PACKAGING)

1.142

29

.900

22.9

.675

17.1

RECOMMENDED

PANEL OPENING

2X #4-40 UNC-2B THRU

.75

19.1

1.40

35.6

1.31

33.4

.07

1.8

KIT INCLUDES:

1- COUPLER

1- FLANGE ADAPTOR

2- #4-40 x 1/4" MOUNTING SCREWS

NOTES:

MATERIAL:

FLANGED ADAPTOR: ZINC ALLOY

HARDWARE: STAINLESS STEEL

FINISH:

FLANGED ADAPTOR: NICKEL PLATE

KIT IS PACKAGED IN ACCORDANCE WITH L-COM SPECIFICATION PS-0031.

C

A

B

C

D

45 BEECHWOOD DRIVE

NORTH ANDOVER, MA

01845

SCALE:

SIZE

CAD FILE:

DWG. NO.

A

SHEET

OF

REV.

DATE

APPROVALS

DRAWN BY

CHECKED BY

APPROVED BY

1

2

3

4

5

6

7

8

THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE

PROPERTY OF L-COM, INC. ANY REPRODUCTION IN PART OR WHOLE

WITHOUT THE WRITTEN PERMISSION OF L-COM, INC. IS PROHIBITED.

A

B

C

D

1

2

3

4

5

6

7

8

ECF504-R5E

C

ECF504-R5E.SLDDRW

1

D. FRISIELLO

12/07/2011

REVISIONS

DESCRIPTION

APPROVED

REV

DATE

D. GALLAGHER

12/07/2011

12/8/11

A

B

INITIAL RELEASE

ECN5990: 2 MOUNTING SCREWS WERE 1 PACKAGE OF SCREWS

02/22/12

D.GRIFFIN

DFP

C

ECN 6492: CHANGED NOTE TO "TDG1026KC-R5E" WITHOUT PKG. UPD LOGO

10/19/12

D. DESJARDIN
