Specifications

System Type

LED Lighting System

Powered or Passive

Powered

Power Consumption LEDs

60 watts per LED

(4 LEDs, 240 watts per pod)

Power Consumption

540VA, 4.5A @ 120VAC Nominal

Stand Mount Size

1 3/8-inch Round

Pole Through Design

Manual Controls

Master Brightness

Lamp Colours

Effect Modes

Colour Chase / Colour Fade /

Audio Chase / Bluetooth

Bluetooth Control App

IOS & Android

DMX

Shielded 3-pin XLR Cable

Sound Active Mode

Integrated Microphone

Audio Input

Line Level or Speaker Level

Dimensions (LWH inches)

32.4 x 5 x 9.5

Dimenstions (LWH cm)

82.3 x 12.75 x 24

Weight

20.8 lbs (9.4 kg)

Box Dimensions (LxWxH, inches)

36 x 10 x 8

Box Dimensions (LxWxH, cm)

91 x 25 x 20

Specifications subject to change without notice

Overview

The LP-LED4PRO is Yorkville Sound’s most powerful lighting module. It

combines high output, flexible control, and touring-grade durability for

vibrant stage shows.

The LP-LED4PRO features eight “Sound Active” modes that react to your

music using the 1/4” input or onboard microphone, and fifteen Fade or

Chase effects provide dynamic, kinetic light shows.

The chassis has a convenient handle on each side, and a pole adapter

runs through the body for mounting under a loudspeaker or stacking.

Multiple units can be linked and controlled by the Yorkville proprietary

communication protocol, DMX, or the free app for iOS, iPad, and Android

over a Bluetooth® connection. Standalone operation is also available,

with 31 preset colours and intuitive onboard controls.

Lightweight, powerful, and simple to use, the LP-LED4PRO is ideal for

performers and DJs who need a high output, portable solution to light up

larger venues.

LP-LED4Pro

HIGH OUTPUT 4-HEAD LED LIGHTING SYSTEM

yorkville.com

The iOS and Android App, via

Bluetooth, controls up to 4

individual LP-LED4X and

LP-LED2X fixtures.

Available for

FREE DOWNLOAD

Type: yorkville LP-control

LP-LED4Pro

Features

l

4 Pods with 4x 60-Watt LEDs each: Red, White, Green,

Blue, Cyan, Amber, and Two Lime Dies

l

Standalone Mode with 31 Preset Colours

l

8 Sound Active Modes with 1/4” Line / Speaker Input

and Integrated Microphone

l

15 Fade or Chase Effects

l

Master Brightness Control

l

External Control by Yorkville Proprietary Communication

Protocol, Integrated DMX I/O, or Mobile App over Bluetooth®

l

Integrated Pole-Through Mount Adapter

l

Made in Canada
