Model: HG908P

Mounting Options

Hyperlink's patch antennas offer several unique mounting options. They can be mounted flat against a wall, or to a mast using

a pair of 2 inch U-bolts. The antennas also accept most tilt-and-swivel security camera brackets equipped with standard 1/4-20

threads.

Description

Part Number

Small Metal Tilt-and-Swivel Mounting Bracket for indoor wall mounting. Includes wall-mounting

hardware.

HGX-PMT02

Medium Plastic Tilt-and-Swivel Mounting Bracket for indoor wall mounting. Includes wall-mounting

hardware.

HGX-PMT03

Large Metal Tilt-and-Swivel Mounting Bracket for indoor and outdoor wall or mast mounting. Includes

wall-mounting hardware. Can be mast-mounted using U-Bolt Kit (sold separately).

HGX-PMT04

Universal Antenna Mount powder coated galvanized steel “DSS-style” arm for outdoor wall mounting.

Requires a pair of 2 inch U-bolts (sold separately).

HGX-UMOUNT

Stationary Mounting Kit for mounting to 1-1/4" to 2" dia. masts. Includes U-Bolts, nuts and mast clamp.

HGX-PMT07

60 Degree Tilt-and-Swivel Mounting Kit for mounting to 1-1/4" to 2" dia. masts. Mounting hardware

included.

HGX-PMT06

Ceiling/Wall Universal Antenna Mount can be used with 4.5" sq and 8.5" sq. patch antennas as well as

N-Type bulkhead and TNC/BNC bulkhead omni directional antennas. Includes ceiling/wall mounting

hardware.

HGX-UMOUNT02

Universal Corner Mounting Bracket: This bracket is designed to mount to an outside corner of a

structure. It can be used with 4.5" and 8.5" sq. patch antennas, radome enclosed Yagi antennas, the

HGX-PMT02 tilt & swivel bracket and can accommodate the SC2402N and SC5802N 2-Way signal

splitters as well as HyperAmp outdoor amplifiers.

HGX-UMOUNT03

Window Mounting Kit Includes suction cups and mounting hardware.

HGX-PMT08
