Model: HG908P

Specifications

Electrical Specifications

Frequency

902-928 MHz

Gain

8 dBi

Horizontal Beam Width

75 degrees

Vertical Beam Width

65 degrees

Impedance

50 Ohm

VSWR

< 1.5:1 avg.

Mechanical Specifications

Weight

< 1 lb. (0.45 kg)

Dimensions

8.5" x 8.5" x 1.2" (0.22 x 0.22 x 0.03

mm)

Radome Material

UV-inhibited Polymer

Flame Rating

UL 94HB

Mounting

Four ¼" Holes

Polarization

Horizontal and Vertical

Operating Temperature

-40° C to 85° C

(-40° F to 185° F)

Wind Survival

>150 MPH

RoHS Compliant

Yes

RF Antenna Gain Patterns
