TABLE ONE - PULLING RANGE & TEMPERATURE FREQUENCY STABILITY ( TFC)

TABLE TWO - OUTPUT WAVEFORM AND LOAD CHARACTERISTICS

Issue : 1 S8

Date : 08/11/04

email :

info@actcrystals.com

Fax :

0044 (0)118 979 1283

Tel :

0044 (0)118 979 1238

3 The Business Centre, Molly Millars Lane, Wokingham, Berkshire, RG41 2EY, UK

http://www.actcrystals.com

ACT7VC14 - VCXO

In line with our ongoing policy of product evolvement and improvement, the above specification may be subject to change without notice

ISO9001:2000 Registered

For quotations or further information please contact us at:

Temperature

Pull Range

TFC

Temperature

Pull Range

TFC

0 - +70

°C

±100PPM Min.

± 5PPM

0 - +70

°C

±250PPM Min.

±30PPM

0 - +70

°C

±100PPM Min.

±10PPM

-20 - +70

°C

±100PPM Min.

±10PPM

0 - +70°C

±100PPM Min.

±20PPM

-20 - +70°C

±100PPM Min.

±20PPM

0 - +70°C

±100PPM Min.

±30PPM

-20 - +70°C

±100PPM Min.

±30PPM

0 - +70°C

±150PPM Min.

± 5PPM

-20 - +70°C

±150PPM Min.

±10PPM

0 - +70°C

±150PPM Min.

±10PPM

-20 - +70°C

±150PPM Min.

±20PPM

0 - +70°C

±150PPM Min.

±20PPM

-20 - +70°C

±150PPM Min.

±30PPM

0 - +70

°C

±150PPM Min.

±30PPM

-20 - +70

°C

±200PPM Min.

±20PPM

0 - +70

°C

±200PPM Min.

±10PPM

-20 - +70

°C

±200PPM Min.

±30PPM

0 - +70

°C

±200PPM Min.

±20PPM

-20 - +70

°C

±200PPM Min.

±40PPM

0 - +70

°C

±200PPM Min.

±30PPM

-20 - +70

°C

±250PPM Min.

±20PPM

0 - +70

°C

±250PPM Min.

±10PPM

-20 - +70

°C

±250PPM Min.

±30PPM

0 - +70°C

±250PPM Min.

±20PPM

-20 - +70°C

±250PPM Min.

±40PPM

Output

Waveform

Frequency

Range

Oscillation

State

Output Characteristics

Clipped Sine

Wave

8MHz -

40MHz

40MHz – 160MHz

F

: Fundamental

O: Overtone

Load: 10kΩ /10pF

Output level: >1Vp-p

TTL

1MHz -

40MHz

40MHz – 160MHz

Load: Max. 10 low power consumption TTL gates

“1” level: >+2.4VDC; “0” level: <+0.2VDC

Duty cycle: 45/55

Rise/fall time: <6ns

HCMOS

1MHz -

40MHz

40MHz – 160MHz

Load: Max. 10 low power consumption TTL/HCMOS

“1” level: >+4.5VDC; “0” level: <+0.5VDC

Duty cycle: 45/55

Rise/fall time: <6ns

ACMOS

1MHz -

40MHz

40MHz - 160MHz

Load: Max. 10 low power consumption TTL/ACMOS

“1” level: >+4.5VDC; “0” level: <+0.5VDC

Duty cycle: 45/55

Rise/fall time: <6ns

Sine Wave

8MHz -

40MHz

40MHz – 160MHz

Load: Nominal value 50Ω

Output level: >2dBm

Harmonic Attenuation: <-25dB

Noise Attenuation: <-75dB

2 of 3
