HyperLink Wireless 2.4 GHz 14 dBi Flat Patch Wireless

LAN Antenna Model: HG2414P

Applications and Features

Applications:



2.4 GHz ISM Band



IEEE 802.11b, 802.11g, 802.11n Wireless LAN



Bluetooth®



Public Wireless Hotspot



WiFi



Wireless Video Systems

Features:



Superior performance



Light weight



Durable UV-stable, UL flame rated radome



Low loss solid brass elements



DC Short lightning protection



12 inch coax lead



Can be installed for either vertical or horizontal polarization



Optional mounting brackets available

Description

Directional Flat Patch Antenna

The HG2414P is a high performance directional flat patch WiFi antenna suitable for indoor and outdoor applications in the

2.4GHz ISM band, including IEEE 802.11b, 802.11g and 802.11n wireless LANs, Bluetooth®, and public wireless hotspots. This

WiFi antenna is lightweight and features an aesthetic UV-stable, UL flame rated white plastic radome which can also be painted

to match the room or building structure. The HG2414P can be installed for horizontal or vertical polarization. It can be wall or

ceiling mounted, as well as mast-mounted using U-bolts.

Specifications

Electrical Specifications

Frequency

2400-2500 MHz

Gain

14 dBi

Horizontal Beam Width

30 degrees

Vertical Beam Width

30 degrees

Impedance

50 Ohm

Max. Input Power

25 Watts

VSWR

< 1.5:1 avg.

Lightning Protection

DC Short
