● Pantograph structured strip holds down one to

multiple flat cables securely.

UL94 V-2

● Nylon 66 （Color：Natural ）

FLAT CABLE CLAMP / FCN-P

・FCC-M

Features

Material

Adhesive tape mounting

32.0

63.5

77.0

2.6

7.0

16.0

Part No.

（A）

FCN-25P-R

FCN-50P-R

FCC-60M-R

12

15

──

B

47

79

90

C

23

50

76

D

32.0

64.0

78.5

Std. Package

100

pcs.

Max. width

Applicable cable

Max. thickness

（Unit: mm）

B

D

C

Double sided adhesive tape

D

B

C

FCN-P-R

FCC-60M-R

Adhesive-mount clamp with pantograph strip to hold down multiple flat cables

●

●

●

（

：

）

●

●

●

（

：

）

Specification drawing

（Unit：mm）

Part No.

Compatible connector

USB plug size

USBCC-B-YR

Type-B USB connector

Refer to Specification drawing

Std. Package

100 pcs.

（Unit：mm）

Part No.

Compatible connector

USB plug size

USBCC-A-YR

Type-A USB connector

Refer to Specification drawing

Std. Package

100 pcs.

(19.5)

21

9

(30)

(8.8)

7.8

A

B side

USB PLUG TYPE A

6.8～8.0

+0.10

11.8－0.05

(10.3)

USB CONNECTOR TYPE A

PCB

8.88±0.2

0

0.3－0.2

1.5MAX

MOUNTING PLATE

(14.5)

11.5±0.1

8.7±0.1

（31.6）

9

22.6

（21.5）

8

（9）

Double sided

adhesive tape

（12）

10.5±0.1

8±0.1

0.9～1.5

0.3 0-0.2

R0.3

R0.3

PCB

USB connector 2.0 type-B

MOUNTING PLATE

MIN11.75

9.3～10.5

USB 2.0 type-B

※This product is assembled on a USB connector with double-sided adhesive.

　Make sure to press the component firmly onto the connector. Assembled product cannot be reused.

※This product is assembled on a USB connector with double-sided adhesive.

　Make sure to press the component firmly onto the connector. Assembled product cannot be reused.
