HyperLink 2.4 GHz 8 dBi Wireless LAN Circular

Polarized Flat Patch Antenna

Applications and Features

Applications:



2.4 GHz ISM Band



IEEE 802.11b and 802.11g Wireless LAN



Bluetooth

®



Public Wireless Hotspot



WiFi

Features:



Superior performance



Compact size, 4.5" Square



Durable UV-stable, UL flame rated radome



Low loss solid brass element



DC Short lightning protecting



12 inch coax lead



Available in right or left hand polarization



Optional mounting brackets available

Model: HG2409PCL

Description

This very compact flat WiFi patch antenna provides 8 dBic gain with very broad coverage. The use of a circular polarized

antenna on a fixed AP can be advantageous if the linear polarized remote links are constantly moving. Circular polarized

antennas have equal response to either horizontal or vertical polarized antennas. It is suitable for both indoor and outdoor

applications in the 2.4GHz ISM band such as IEEE 802.11b and 802.11g, Bluetooth® and for public wireless hotspot

applications. Available in left or right circular polarization, this antenna's construction features a sealed internal brass element

and an aesthetic UV-stable, UL-flame rated white polymer radome. Can be wall or ceiling mounted, as well as mast-mounted

using U-bolts.
