Application examples

FIBER GUIDE / OFG-5042-R30

Features

● Optical fiber bending radius of 30 mm or higher can be retained.

● Hook and loop fastener applicable member is equipped for

optical fiber bundle.

● The guide is fixable on a sheet metal with countersunk screws.

Material

UL94 V-2

● Nylon 66

（Color：Natural）

The guide retains the minimum bending radius for optical fibers

（ Unit：mm）

Part No.

Applicable screw

Mounting hole size

Refer to Specification

drawing

M4 counter

screw

OFG-5042-R30

≦10

≦2

25

50

φ4.5

46

R30

2

（21.4）

（5）

3.5

A-A

25±0.2

φ4.5±0.1 or M4 Screw hole

Mounting hole

A

A

Screw mounting

M4 counter Screw

Metal plate etc.

Velcro tape

Optical fiber bundle

Applicable velcro tape

Width

Thickness

Maintaining Min.

bend radius of cables

Std. Package

50 pcs.

76
