[General Specifications]

100V AC 50/60Hz

220V AC 50/60Hz

Model

Rated Voltage

Operating Ambient Humidity

Less than 85 ％RH (No condensation)

RFV-24F

24V DC

RFV-100F

RFV-220F

-10℃ ～ 50℃

Mounting Location

Operating Ambient Temperature

3,000cd or more

3,000cd or more

2,500cd or more

2,000cd or more

(for Bit Input Mode)

Red

Yellow

Green

Blue

Indoor

: Upright and inverted mounting

Outdoor : Upright direction Only

Light Source

Color

Luminous Intenzsithpy

Flashing Rate

Indoors and Outdoors

Operating Voltage Range

Power Consumption

Use Upright if water splashing is present

Bit Input ：　4　／　Binary Input ： 15

300ms or less （ In case of signal line startup )

1s or less ( In case of power supply startup )

Number of Playback Sounds

Playback Start Up Time

Channel Priority Order

LED

115±15 Flashes Per Minute

Revolving

Light

SD Card Format

FAT16

Pulse input (Pulse width more than 100msec)

Signal Input Method

Mounting Direction

Channel Input Type

Forced playing mode (Set Operation Mode Selection switch

No.1:Either ON or OFF/ No.2: ON )

CH1 is played when the power is turned on.

It ignores any inputs other than volume.

Bit Input (Set Operation Mode Selection switch No.1: OFF / No.2: OFF )

Binary Input (Set Operation Mode Selection switch No.1: ON / No.2: OFF )

STOP ＞ CH4 ＞CH3 ＞ CH2 ＞ CH1

Standard bit rate ： 64kbit/s 、Fs=44.1kHz

Playback Time

63sec （At playing of 64kbit/s 、Fs=44.1kHz Monaural data)

Internal Memory

508KByte （Total of MP3 data）

Supported Memory Card

SD Card (SDHC,SDXC are Not supported)

Recommended Parts : SDV-2GP□ (option)

Sound reduction input ： -20dB ± 2dB (Sound reduction mode only)

MPEG1-Audio Layer Ⅲ (MP3)

Sound Reduction

Rated Voltage ±10%

Max.18W

Max.16W

Max.16W

Audio Format

Max.95dB or more.

Mounted to a 300mm x 300mm base at a distance of 1.0 meter in front

of the base surface playing sound 0dB 1kHz Sine wave,

with volume adjustable.

※Sound level of message will vary with the surrounding environment.

Sound Pressure Level

Page

SPECIFICATIONS

Drawing No.

Rev.

G

1/3

RFV-100F-W18
