E5CSV

Specifications

■ Ratings

Note: 1. Do not use an inverter output as the power supply. (Refer to Safety Precautions for All Temperature Controllers.)

2. Models for 24 VAC/DC can also be manufactured.

■ Characteristics

Note: 1. The following exceptions apply to thermocouples.

• U, L: ±2°C ±1 digit max.

• R:

±3

°C ±1 digit max. at 200°C or less

2. The following exceptions apply to platinum resistance thermometers.

Input set values 0, 1, 2, 3 for E5CSV: 0.5% FS ±1 digit max.

3. Industrial electromagnetic environment (EN/IEC 61326-1 Table 2)

Supply voltage

100 to 240 VAC, 50/60 Hz

24 VAC, 50/60 Hz; 24 VDC

Operating voltage range

85% to 110% of rated supply voltage

Power consumption

100 to 240 VAC: 5 VA

24 VAC: 3 VA, 24 VDC: 2 W

Sensor input

Thermocouple input type:

K, J, L

Platinum resistance thermometer input type:

Pt100, JPt100

Universal-input (thermocouple/platinum resistance thermometer) type: K, J, L, T, U, N, R, Pt100, JPt100

Control

output

Relay output

SPST-NO, 250 VAC, 3A (resistive load)

Voltage output (for driving the SSR) 12 VDC, 21 mA (with short-circuit protection circuit)

Control method

ON/OFF or 2-PID (with auto-tuning)

Alarm output

SPST-NO, 250 VAC, 1A (resistive load)

Setting method

Digital setting using front panel keys

Indication method

7-segment digital display (character height: 13.5 mm) and deviation indicators

Other functions

• Setting change prohibit (key protection)

• Input shift

• Temperature unit change (°C/°F)

• Direct/reverse operation

• Temperature range, Sensor switching (K/J/L, Pt100/JPt100)

• Switching is performed between a thermocouple and platinum resistance thermometer for universal-input models.

• Control period switching

• 8-mode alarm output

• Sensor error detection

Ambient operating temperature

−10 to 55°C (with no condensation or icing); with 3-year guarantee: −10 to 50°C

Ambient operating humidity

25% to 85%

Storage temperature

−25 to 65°C (with no condensation or icing)

Setting accuracy

Thermocouple (See note 1.):

(±0.5% of indication value or ±1

°C, whichever is greater) ±1 digit max.

Platinum resistance thermometer (See note 2.): (±0.5% of indication value or ±1

°C, whichever is greater) ±1 digit max.

Indication accuracy

(ambient temperature of 23

°C)

Influence of temperature

R thermocouple inputs:

(±1% of PV or ±10

°C, whichever is greater) ±1 digit max.

Other thermocouple inputs:

(±1% of PV or ±4

°C, whichever is greater) ±1 digit max.

Platinum resistance thermometer inputs: (±1% of PV or ±2

°C, whichever is greater) ±1 digit max.

Influence of voltage

Influence of EMS. (at EN61326-1)

Hysteresis (for ON/OFF control)

0.2% FS (0.1% FS for universal-input (thermocouple/platinum resistance thermometer) models)

Proportional band (P)

1 to 999

°C (automatic adjustment using auto-tuning/self-tuning)

Integral time (I)

1 to 1,999 s (automatic adjustment using auto-tuning/self-tuning

Derivative time (D)

1 to 1,999 s (automatic adjustment using auto-tuning/self-tuning)

Alarm output range

Absolute-value alarm: Same as the control range

Other:

0 to input setting range full scale (

°C or °F)

Alarm hysteresis:

0.2

°C or °F (fixed)

Control period

2/20 s

Sampling period

500 ms

Insulation resistance

20 M

Ω min. (at 500 VDC)

Dielectric strength

2,000 VAC, 50/60 Hz for 1 min between current-carrying terminals of different polarity

Vibration

resistance

Malfunction 10 to 55 Hz, 20 m/s2 for 10 min each in X, Y, and Z directions

Destruction 10 to 55 Hz, 0.75-mm single amplitude for 2 hr each in X, Y, and Z directions

Shock resistance

Malfunction 100 m/s2 min., 3 times each in 6 directions

Destruction 300 m/s2 min., 3 times each in 6 directions

Life expectancy

Electrical

100,000 operations min. (relay output models)

Weight

Approx. 120 g (Controller only)

Degree of protection

Front panel: Equivalent to IP66; Rear case: IP20; Terminals: IP00

Memory protection

EEPROM (non-volatile memory) (number of writes: 1,000,000)

EMC

EMI Radiated:

EN 55011 Group 1 Class A

EMI Conducted:

EN 55011 Group 1 Class A

ESD Immunity:

EN 61000-4-2: 4 kV contact discharge (level 2)

8 kV air discharge (level 3)

Radiated Electromagnetic Field Immunity:

EN 61000-4-3: 10 V/m (80-1000 MHz, 1.4-2.0 GHz amplitude modulated) (level 3)

10 V/m (900 MHz pulse modulated)

Conducted Disturbance Immunity:

EN 61000-4-6: 3 V (0.15 to 80 MHz) (level 2)

Noise Immunity (First Transient Burst Noise): EN 61000-4-4

Burst Immunity:

2 kV power-line (level 3), 1 kV I/O signal-line (level 3)

Surge Immunity:

EN 61000-4-5: Power line:

Normal mode 1 kV; Common mode 2 kV

Output line (relay output): Normal mode 1 kV; Common mode 2 kV

Voltage Dip/Interrupting Immunity:

EN 61000-4-11 0.5 cycle, 100% (rated voltage)

Approved standards

UL 61010-1 (listing)

CSA C22.2 No.1010-1

Conformed standards

EN61326-1 (See note 3.), EN61010-1, IEC61010-1

VDE 0106 Part 100 (finger protection), when the terminal cover is mounted.
