E52

51

Model Number Legend

The type of protective tubing length, and lead length can be specified as shown below.

Example:

Element: K, protective tubing length: 12 cm, exposed leads, Y-type crimp terminals for M3.0, protective tubing diameter: 1 mm, flexible and heat

resistive, lead length: 2 m

E52-CA12AY D=1 S2 2M

Special models for Packaging Machines

E5 2-CA

@ A @ D=1 S @

@M

Code

Element type

CA

K

Diameter (D)

Length (L)

1.0

6

1.0

12

1.0

3 to 100

(in centimeters, variable)

Code

Terminal type

A

Exposed lead wires

Code

Terminal processing

Y

Y-type crimp terminals for M3.0

F

Ferrules

Code

Lead wire length M (m)

Specify the M length in meters.

Range: 0.5, 1, 2, or 0.5 to 12 (in meters, variable)

Protective tubing length L (cm)

Specify the length in centimeters within the

following range: Unit (cm)

Protective tubing diameter (D)

D=1

1 mm

Protective tubing structure

Sheathed

Code

Application

S

Temperature sensors for packaging machines

Code

Compensating conductor

2

Flexible and heat resistant (30 cores)

1

Heat resistant (7 cores)
