LCD: Liquid Crystal Display , TP: Touch Panel , LCM: Liquid Crystal Module

No

Items to be

inspected

Criteria

Classification of

defects

1

Functional defects

1) No display, Open or miss line

2) Display abnormally, Short

3) Backlight no lighting, abnormal lighting.

4) TP no function

Major

2

Missing

Missing component

3

Outline dimension

Overall outline dimension beyond the drawing

is not allowed

4

Color tone

Color unevenness, refer to limited sample

Minor

5

Soldering

appearance

Good soldering , Peeling off is not allowed.

6

LCD/Polarizer/TP

Black/White spot/line, scratch, crack, etc.

7.1.4 Criteria (Visual)

Number

Items

Criteria(mm)

1.0

LCD

Crack/Broken

NOTE:

X: Length

Y: Width

(1) The edge of LCD broken

X

Y

Z

≤3.0mm

<Inner border line

of the seal

≤T

Page 21 of 27
