1 OSLON® Square Uniform White PowerStars CRI90

ILH-OU01-xx90-SC221-WIR200

Product Overview

At the heart of each OSLON® Square Uniform PowerStar is one

of the worlds most compact 2W high power LEDs with extremely

low thermal resistance, remarkable high efficiency, highly reliable

and superior corrosion robustness. The OSLON Square Uniform

has an improved radiation pattern and superior color-over-angle

performance. PowerStars are compact, powerful LED light sources

built on aluminium substrates for optimal thermal management.

Available with 200mm wires as standard.

Applications

z

General Lighting

z

Spot Lighting

z

Task Lighting

z

Decorative Lighting

z

Horticultural Lighting

z

Retail and Entertainment Lighting

z

Wall-washing

z

Architectural lighting

Technical Features

z

OSLON® Square Uniform PowerStars contain a single OSRAM Opto Semiconductors OSLON® Square Uniform

LED

z

Up to 100,000 hours lifetime to 70% of original brightness

z

Mounting holes using M3 screws allow easy installation

z

Size (LxWxH): 20x20x3.62mm

z

PowerStars can be linked together to produce longer chains

z

Current range 200mA to 1800mA*

z

High CRI 90 minimum

z

Suitable Heatsinks available - please see Heatsink section

z

Suitable Lenses available - Please see Lens section

z

Suitable Drivers available - Please see drivers section

z

Suitable Thermal Interface Material available – Please see Thermal Interface Material section

*This datasheet should be read in conjunction with the relevant OSRAM Opto Semiconductors data on the LED used
