EGF3AB – EGF3KB

TAITRON COMPONENTS INCORPORATED www.taitroncomponents.com

Page 1 of 5

Tel: (800)-TAITRON (800)-824-8766 (661)-257-6060

Fax: (800)-TAITFAX

(800)-824-8329 (661)-257-6415

3.0A Sintered Glass Passivated

Super Fast Rectifier

3.0A Sintered Glass Passivated Super Fast Rectifier

Features

• Sintered glass passivated (SGP) rectifier chip

• Glass passivated cavity-free junction

• Ideal for surface mount automotive applications

• Built-in strain relief

• Easy pick and place

• High temperature soldering guaranteed:250°C/10 seconds,

at terminals

• RoHS Compliance

Mechanical Data

Case:

JEDEC DO-214AA(SMB) molded plastic over passivated chip

Epoxy:

Plastic package has UL flammability classification 94V-0

Terminals:

Solder plated, solderable per MIL-STD-750, Method 2026

Polarity:

Color band denotes cathode end

Weight:

0.003 ounce, 0.093 gram

Maximum Ratings and Electrical Characteristics (T A=25ºC unless noted otherwise)

Symbol

Description

EGF3AB

EGF3BB

EGF3DB

EGF3GB

EGF3JB

EGF3KB

Unit

Conditions

VRRM

Maximum

Repetitive Peak

Reverse Voltage

50

100

200

400

600

800

V

VRMS

Maximum RMS

Voltage

35

70

140

280

420

560

V

VDC

Maximum DC

Blocking Voltage

50

100

200

400

600

800

V

IF(AV)

Maximum Average

Forward Rectified

Current

3.0

A

TL=110° C

IFSM

Peak Forward

Surge Current

115

105

A

8.3ms single half

sine-wave

superimposed on

rated load (JEDEC

Method)

SMB
