ISO 9001 ISO 14001 CERTIFIED

Mini-Circuits

®

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site

The Design Engineers Search Engine Provides ACTUAL Data Instantly From MINI-CIRCUITS At: www.minicircuits.com

RF/IF MICROWAVE COMPONENTS

minicircuits.com

ALL NEW

50

Digital Step Attenuator

Precision

TOAT-R512+

TOAT-R512

CASE STYLE: QQ96

PRICE: $64.45 ea. QTY (1-9)

Maximum Ratings

Pin Connections

Features

Operating Temperature

-55°C to 100°C

Storage Temperature

-55°C to 125°C

Input Power

15 dBm

DC Voltage

5.5 V

TTL

5.5V

Outline Drawing

Digital Step Attenuator Electrical Specifications

REV. A

M109143

TOAT-R512

DJ/VV/CP

070326

Page 1 of 2

MODEL

NO.

FREQUENCY

(MHz)

PRIMARY ATTENUATION STEPS

(dB)

@TTL CONTROL PORT

ATTENUATION

(dB)

VSWR

(:1)

f

L

f

U

#1

#2

#3

(1,1,1)**

Nom.

(0,0,0)

Max.

LM

U

TOAT-R512(+)

10

1000

0.5±0.18

1±0.25

2±0.25

3.5

4.0

1.6

1.4

1.5

Applications

** Total attenuation above thru-loss.

1. Step accuracy is specified for basic steps. For combination of steps accuracy is additive.

2. Thru-loss is minimum insertion loss with all attenuation elements bypassed (All TTL controls state are Low)

3. For optimum operation of TOAT models, ensure the device case is properly connected to the ground plane (of PC board)

Additional Specifications

DC Voltage

+5V

DC Current

12mA max.

Switching Time (50% TTL to within specified

accuracy of the next-selected attenuation step,

and to within 0.1 dB of steady-state Thru-Loss)

10µs typ., 15µs max.,

TTL Input High Threshold

2V min

TTL Input Low Threshold

0.8V max.

TTL Toggle Rate

50 kHz typ.

1dB Compression

0 dBm (10-100 MHz)

+10 dBm (100-1000MHz)

L=10 to 100 MHz

M=100 to 500 MHz

U=500 to 1000 MHz

• wideband, 10 to 1000 MHz

• excellent step accuracy, 0.2 dB typ.

• excellent VSWR 1.3 typ.

• low DC current, 6 mA typ.

• hermetic, metal, TO-8 case

• base stations

• cellular

• test-sets

• military, hi-rel applications

RF IN

4

RF OUT

11

TTL CONTROL #1

2

TTL CONTROL #2

3

TTL CONTROL #3

1

+5V DC

12

CASE GROUND

5,6,7,8,9,10

+ RoHS compliant in accordance

with EU Directive (2002/95/EC)

The +Suffix identifies RoHS Compliance. See our web site

for RoHS Compliance methodologies and qualifications.

Outline Dimensions (

)

Electrical Schematic

inch

mm

A

BC

D

E

F

.600

.250

.25

.016

.020

.04

15.24

6.35

6.35

0.41

0.51

1.02

GH

J

K

wt

.400

.200

.200

.100

grams

10.16

5.08

5.08

2.54

4.00
