Aluminum Capacitors

ECV

Vishay Roederstein

FEATURES

• Polarized aluminum electrolytic capacitors

• SMD style

• Miniature dimension

• Extended temperature range: 105 °C

• Reflow soldering

• RoHS compliant

APPLICATIONS

• Industrial electronics, automotive electronics,

telecommunication systems

• Smoothing and filtering

• Miniature power supply units, dc-to-dc converters

PACKAGING

• Supplied in blister tape

QUICK REFERENCE DATA

DESCRIPTION

UNIT

VALUE

Nominal case size (Ø D x L)

mm

4 x 5.3 to 12.5 x 13.5

µF

10 to 2200

Capacitance tolerance

%

± 20

Rated voltage range

V

6.3 to 50

Category temperature range

°C

- 40 to 105

Load life

h

2000

Based on sectional

specification

IEC 60384-4/

EN130300

Climatic category

IEC 60068

40/105/56

RoHS

COMPLIANT

(µF)

RATED VOLTAGE (V)

6.3

1016

253550

10

→→

4 x 5.3

→

5 x 5.3

6.3 x 5.8

22

→→→

6.3 x 5.8

6.3 x 5.8

8 x 6.2

33

→→

6.3 x 5.8

6.3 x 5.8

8 x 6.2

8 x 10

47

5 x 5.3

→

6.3 x 5.8

8 x 6.2

8 x 10

10 x 10

100

→

6.3 x 5.8

→

8 x 10

→

10 x 10

220

→

8 x 10

10 x 10

→

10 x 10

12.5 x 13.5

330

8 x 10

→

10 x 10

10 x 10

12.5 x 13.5

-

470

→

10 x 10

10 x 10

10 x 10

12.5 x 13.5

-

680

→→→

12.5 x 13.5

-

-

1000

→

10 x 10

12.5 x 13.5

-

-

-

1500

10 x 10

12.5 x 13.5

-

-

-

-

2200

12.5 x 13.5

-

-

-

-

-
