CDH-C-R datasheet(1/1 Pages) ADAM-TECH

部件名	CDH-C-R

功能描述	.100 LATCHING HEADER & HOUSING

PDF	1 Pages

Scroll/Zoom	100%

制造商	ADAM-TECH [Adam Technologies, Inc.]

网页	http://www.adam-tech.com

标志

1 / 1 page

Adam Technologies, Inc.

909 Rahway Avenue • Union, New Jersey 07083 • T: 908-687-5000 • F: 908-687-5710 • WWW.ADAM-TECH.COM

279

909 Rahway Avenue • Union, New Jersey 07083 • T: 908-687-5000 • F: 908-687-5710 • WWW.ADAM-TECH.COM

.041

[1.04]

4 POSITION SHOWN

A = .100 [2.54] X No. of SPACES

B = .100 [2.54] X No. of SPACES + .200 [5.08]

RECOMMENDED

PCB LAYOUT

ø.040 [1.02]

B

.453 [11.50]

A

.100 [2.54]

.492 [12.50]

.150 [3.80]

.266

[6.75]

.132 [3.35]

.466 [11.85]

.100 [2.54]

A

.200

[5.08]

.118 [3.00]

RECOMMENDED

PCB LAYOUT

.041 [1.04]

4 POSITION SHOWN

CDR-04-TR

A = .100 [2.54] X No. of SPACES

B = .100 [2.54] X No. of SPACES + .200 [5.08]

.134 [3.40]

.266

[6.75]

.100 [2.54]

A

.200 [5.08]

B

.118 [3.00]

.100 [2.54]

A

.040 [1.02]

CDR-C-X

CDR-H-04

.051 [1.30]

.061 [1.55]

.508 [12.90]

.600 [15.24]

A

B

.100 [2.54]

.040

[1.02]

.100 [2.54]

.05

[1.27]

C

.025 [0.64]

.453

[11.50]

Recommended PCB Layout

.100" LATCHING

HEADER & HOUSING

CDR SERIES

CDR-06-TS

CDH-C-R

CONTACT

CDR-06-TR

CDR-H-04

.600 [15.24]

A

B

.100 [2.54]

.05 [1.27]

.040

[1.02]

.099 [2.51]

A = .100 [2.54] X No. of SPACES

B = .100 [2.54] X No. of SPACES + .099 [2.51]

CDH

HOUSING

Recommended PCB Layout

CDR

STRAIGHT PCB MOUNT

CDR

RIGHT ANGLE PCB MOUNT

CDH-04
