Rev. 1.08.09_149

LPS50-M Series

1 of 3

Embedded Power for

Business-Critical Continuity

LPS50-M Series

60 Watts

Special Features

•MedicalSafetyApprovals

•Universalinput

•Lessthan1Uhigh

•2”x4”footprint

•Remotesense

•Overloadandshortcircuit

protection

•Adjustableoutputvoltage

•Highefficiency

•HighMTBF

•BuiltinEMIfilter

(CISPR22ClassB)

•LEDpowergoodindicator

•Inputpower<74watts

•ComplieswithEN61000-3-2

•ULClassIapproved

•LPX50enclosurekitavailable

•DualACfuses

Total Power:

55-60Watts

Input Voltage:

90-264VAC

127-300VDC

# of Outputs:

Single

Electrical Specifications

Safety

Input

Inputrange:

90-264VAC(widerange)127-300Vdc

Frequency:

47-440Hz

Inrushcurrent:

<60Apeak@230VAC,coldstart@25°C

Inputpower:

<74Watts

Efficiency:

80%-85%typicalatfullload

EMI/RFI:

FCCClassBconducted;CISPR22ClassBconducted;EN55022ClassB

conducted,VDE0878PT3ClassBconducted

Safetygroundleakage

current:

275uA@50/60Hz;264VACinput

Output

Maximumpower:

60Wforconvection(LPS52,55W)

Adjustmentrange:

±20%minimum

Hold-uptime:

10/20ms115/230VACinputline

Overloadprotection:

Shortcircuitprotectiononalloutputs.Caseoverloadprotected@

110-160%ofnormalrating

Overvoltageprotection: 30-50%abovenominaloutput

Remotesense:

Compensatesdfor0.5Vleaddropmax.Willoperatewithoutremotesense

connected.Reverseconnectionprotected.

UL:

UL60601-1

CSA: CSA-C22.2No.601.1-M90

VDE: EN60601-1

CE:

LVD&EMC

•

•

•

•
