MCL

multilayer ferrite inductor

features

eliminates crosstalk and provides high reliability

in a wide temperature and humidity range

solderability

EU RoHS requirements

For further information on packaging, please refer to Appendix A.

ordering information

K: ±10%

M: ±20%

T: Sn

047 = 0.047µH

R10 = 0.100µH

1J

2A

2B

TD: 7" paper tape

(1J - 4,000 pieces/reel

2A - 0.047µH ~ 2.2µH =

4,000 pieces/reel)

TE: 7" embossed plastic

(2A - 2.7µH ~ 10µH =

3,000 pieces/reel

2B - 3,000 pieces/reel)

MCL

Type

Size

Code

Nominal

Inductance

Tolerance

Termination

Material

Packaging

New Part #

1J

Permeability

Code:

H

J

Material

H

TE

R10

K

T

dimensions and construction

W

L

d

t

d

Terminations

(Metallization

Bands)

Electrodes

Ni

Plating

Silver

Metallization

Solder

Plating

L

.063±.006

(1.6±0.15)

.031±.006

(0.8±0.15)

.014±.006

(0.36±0.15)

.031±.006

(0.8±0.15)

Wt

d

Dimensions inches

(mm)

1J

(0603)

.079±.008

(2.0±0.2)

.049±.008

(1.25±0.2)

.02±.01

(0.51±0.25)

.035±.008

(0.9±0.2)

2A

(0805)

.126±.008

(3.2±0.2)

.063±.008

(1.6±0.2)

.02±.01

(0.51±0.25)

.043±.008

(1.1±0.2)

2B

(1206)

Size

Code

Part

Designation

Inductance

L (µH)

Minimum

Q

applications and ratings

DC

Resistance

Maximum

(

Ω)

Allowable

DC Current

Maximum

(mA)

L.Q. Test

Frequency

(MHz)

Self Resonant

Frequency

Typical

(MHz)

0.047

0.068

10

15

50

260

250

0.30

0.50

0.60

0.80

50

245

240

205

180

165

150

136

25

0.082

0.10

0.12

0.15

0.18

0.22

0.27

Operating

Temperature

Range

MCL1JHTTD047M

MCL1JHTTD068M

MCL1JHTTD082M

MCL1JHTTDR10*

MCL1JHTTDR12*

MCL1JHTTDR15*

MCL1JHTTDR18*

MCL1JHTTDR22*

MCL1JHTTDR27*

-55°C

to

+125°C

* Add tolerance character (K, M) - Other tolerances available upon request
