Agency Listings

Photoelectric

Smoke Detectors

significant advancement in conventional detection.

The i3 family is founded on three principles: installation

ease, intelligence, and instant inspection.

Features

Plug-in detector line, mounting base included

Large wire entry port

In-line terminals with SEMS screws

Mounts to octagonal and single-gang backboxes, 4-square

backboxes, or direct to ceiling

Stop-Drop ’N Lock attachment to base

Removable detector cover and chamber

Built-in remote maintenance signaling

Drift compensation and smoothing algorithms

Simplified sensitivity measurement

Wide angle, dual color LED indication

Loop testing via EZ Walk feature

Built-in test switch

•

•

•

•

•

•

•

•

•

•

•

•

Installation ease. The i3 line redefines installation ease with its

plug-in design. This allows an installer to pre-wire the bases included

with the heads. The large wire entry port and in-line terminals

provide ample room for neatly routing the wiring inside the base.

The base accommodates a variety of back box mounting methods,

as well as direct mounting with drywall anchors. To complete the

installation, i3 heads plug in to the base with a simple Stop-Drop ’N

Intelligence. i3 detectors offer a number of intelligent features

to simplify testing and maintenance. Drift compensation and

smoothing algorithms are standard with the i3 line to minimize

nuisance alarms. Two-wire i3 detectors needing cleaning can

generate a remote maintenance signal, when connected to the

2W-MOD2 loop test/maintenance module, or to a panel equipped

with the i3 protocol. This signal is indicated by LEDs located at the

module and the panel. The SENS-RDR, a wireless device, displays the

sensitivityof i3 detectors in terms of percent per-foot-obscuration.

Instant inspection. The i3 series provides wide-angle red and

green LED indicators for instant inspection of the detector’s

condition: normal standby, out-of-sensitivity, alarm, or freeze trouble.

When connected to the 2W-MOD2 loop test/maintenance module

or a panel with the i3 protocol, the EZ Walk loop test feature is

available on two-wire i3 detectors. This feature verifies the initiating

loop wiring by providing LED status indication at each detector.

2093

290-01-E

7272-1209:210

3011446

S911
