Pluggables

C. Fast Ethernet Copper-to-Fiber Conversion

Converting from copper to fiber and back again, SFP-SW10/100R and optical SFPs are used as interfaces in data rate independent Fiber Driver SFP-to-

SFP pluggable media modules (EM316-2SFP). The fiber link operates at Fast Ethernet speed. The SFP-SW10/100 matches the speed and duplex mode of

each edge device, allowing them operate at different speeds and duplex modes.

B. SFP-Enabled GbE Switch/Router

The SFP-GA-R is used in an SFP-enabled GbE switch or router to link to a server configured with a copper GbE NIC.

Switch/Router

Server

Redundant GbE

Fiber Links

Switch/Router

Switch/Router

Network

Redundant GbE

Copper Links

EM316DMR module with

SFP-GCs and optical SFPs

in a 1-slot Chassis

A. Gigabit Ethernet Copper-to-Fiber Conversion with Redundancy

SFP-GCs are used in combination with the Fiber Driver Dual Multi-Rate Transponder (EM316DMR3G-3R) to create

edge-to-edge redundant Gigabit copper links.

Network

Redundant GbE

Copper Links

Switch/Router

Workstation

100Base-TX

Copper

100Base-TX

Copper

GbE Single Mode

EM316-2SFP module with

SFP-SW10/100R and

optical SFP in a 1-slot Chassis
