MECHANICAL DIMENSIONS: Inches (mm)

TOLERANCES: 2 PL DEC ±0.02 (±0.51)

3 PL DEC ±0.010 (±0.254)

LEAD DIMENSIONS: 0.025 (0.635) x 0.025 (0.635) NOMINAL

RECOMMENDED PC BOARD FINISHED HOLE DIAMETER:

0.042 ±0.003 (1.067 ±0.076)

PIN #1

IDENTIFIER

FRONT VIEW

+5V SUPPLY

DISPLAY TEST

5V RETURN

DP3

DP2

DP1

1

2

3

4

5

6

12

11

10

9

8

7

(–) INPUT LO

(+) INPUT HI

ANALOG COMMON

+1.23V REFERENCE OUT

REFERENCE OUT

REFERENCE IN

DP1

DP2

DP3

2.17

(55.1)

2.09

(53.1)

1.80

(45.7)

0.25 (6.4) TYP.

0.15

(3.7)

TYP.

0.040

(1.02)

0.040

(1.02)

0.10

(2.5)

TYP.

0.50

(12.7)

0.17

(4.3)

TYP.

0.92

(23.4)

0.84

(21.3)

0.560

(14.22)

0.040

(1.02)

0.250

(6.35)

0.260

(6.60)

PIN 1

CALIBRATION POTENTIOMETER HOLE LOCATION

0.125 (3.175) DIAMETER

(USE ONLY WHEN PC BOARD MOUNTING)

#2-56 INSERT

0.156 (3.96) DEEP

FRONT VIEW

1.270

(32.26)

0.187

(4.75)

DMS-BZL1 and DMS-BZL2

2.35 (59.69)

2.118 (53.80)

0.093 (2.362) DIAMETER (4 REQUIRED)

INTERNAL CORNER RADII:

0.032 (0.81) MAX.

1.07

(27.18)

0.878

(22.30)

0.096

(2.44)

0.116

(2.95)

2.55 (64.77)

DMS-BZL1 & BZL2

PANEL CUTOUT

BEZEL INSTALLATION

PANEL

BEZEL

GASKET *

* Sealing gasket is supplied with the DMS-BZL2 and DMS-BZL4

RETAINING CLIP INSTALLATION

PANEL

BEZEL INSTALLATION AND RECOMMENDED DRILL AND PANEL CUTOUT

MECHANICAL SPECIFICATIONS

DMS-30PC Series

3½ Digit, LED Display Low-Power,

Miniature Digital Panel Voltmeters

MPM_DMS_30PC.F03 Page 6 of 6
