ISO 9001 ISO 14001 CERTIFIED

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site

The Design Engineers Search Engine Provides ACTUAL Data Instantly From MINI-CIRCUITS At: www.minicircuits.com

RF/IF MICROWAVE COMPONENTS

minicircuits.com

ALL NE

W

Page 1 of 2

Frequency

(MHz)

Conversion

Loss

(dB)

Isolation

L-R

(dB)

Isolation

L-I

(dB)

VSWR

RF Port

(:1)

VSWR

LO Port

(:1)

RF

LO

LO

+7dBm

LO

+7dBm

LO

+7dBm

LO

+7dBm

LO

+7dBm

Level 7 (LO Power +7 dBm) 1500 to 2800 MHz

High Reliability Mixer

Surface Mount

Demo Board MCL P/N: TB-02

Suggested PCB Layout (PL-051)

Outline Dimensions (

)

inch

mm

Maximum Ratings

Pin Connections

Outline Drawing

Electrical Specifications

Typical Performance Data

Electrical Schematic

Features

• hermetically sealed ceramic quad

• low conversion loss, 5.8 dB typ.

• excellent L-R isolation, 30 dB typ.

• low profile package

• aqueous washable

• protected by US Patent 6,133,525

Applications

• digital cellular

• digital cordless phone

• PCN

ADE-R20+

FREQUENCY

(MHz)

CONVERSION LOSS

(dB)

LO-RF ISOLATION

(dB)

LO-IF ISOLATION

(dB)

IP3

at center

band

(dBm)

LO/RF

IF

f

—

X

σ

Total

Range

Max.

Typ. Min.

Typ. Min.

Typ.

1500-2800

DC-500

5.8

0.10

8.0

30

22

28

15

12

1 dB COMP.: +1 dBm typ.

PCB Land Pattern

Suggested Layout,

Tolerance to be within ±.002

LO

6

RF

4

IF

3

GROUND

1,2,5

REV. OR

M109914

ADE-R20+

ED-12872/8

WL/TD/QL

070516

A

B

C

D

E

F

G

.272

.310

.220

.100

.112

.055

.100

6.91

7.87

5.59

2.54

2.84

1.40

2.54

H

J

K

L

wt

.030

.026

.065

.300

grams

0.76

0.66

1.65

7.62

0.20

Operating Temperature

-40°C to 85°C

Storage Temperature

-55°C to 100°C

RF Power

50mW

IF Current

40mA

CASE STYLE: CD542

PRICE: $5.35 ea. QTY. (10-49)

1460.00

1490.00

6.21

37.65

20.28

1.34

1.81

1560.00

1590.00

5.95

37.70

22.72

1.28

1.80

1660.00

1690.00

5.94

36.06

25.56

1.50

1.79

1740.00

1770.00

5.91

35.29

27.83

1.66

1.79

1840.00

1870.00

5.80

33.78

30.47

1.75

1.83

1920.00

1950.00

5.79

32.65

32.64

1.83

1.86

2020.00

2050.00

5.79

31.63

35.32

1.90

1.92

2100.00

2130.00

5.81

30.85

37.17

1.92

1.95

2200.00

2230.00

5.78

30.15

39.95

1.90

2.00

2280.00

2310.00

5.80

29.99

41.69

1.84

2.08

2380.00

2410.00

5.74

30.06

43.43

1.74

2.17

2460.00

2490.00

5.72

30.05

44.18

1.70

2.16

2560.00

2590.00

5.75

29.85

45.60

1.70

2.28

2640.00

2670.00

5.90

30.06

45.88

1.73

2.36

2740.00

2770.00

6.08

30.64

44.97

1.77

2.41

2820.00

2850.00

6.35

31.39

43.67

1.91

2.42

+ RoHS compliant in accordance

with EU Directive (2002/95/EC)

The +Suffix has been added in order to identify RoHS

Compliance. See our web site for RoHS Compliance

methodologies and qualifications.
