FREQUENCY

(MHz)

CONVERSION LOSS

(dB)

LO-RF ISOLATION

(dB)

LO-IF ISOLATION

(dB)

IP3

at center

band

(dBm)

LO/RF

IF

f

—

X

σ

Max.

Typ. Min.

Typ. Min.

Typ.

300-1000

DC-200

5.9

0.10

7.5

38 25

28 20

13

1 dB COMP.: +1 dBm typ.

ISO 9001 ISO 14001 CERTIFIED

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site

The Design Engineers Search Engine Provides ACTUAL Data Instantly From MINI-CIRCUITS At: www.minicircuits.com

RF/IF MICROWAVE COMPONENTS

minicircuits.com

ALL NE

W

Page 1 of 2

PCB Land Pattern

Suggested Layout,

Tolerance to be within ±.002

Level 7 (LO Power +7 dBm) 300 to 1000 MHz

High Reliability Mixer

Surface Mount

Demo Board MCL P/N: TB-02

Suggested PCB Layout (PL-051)

Outline Dimensions (

)

inch

mm

Maximum Ratings

Pin Connections

LO

6

RF

4

IF

3

GROUND

1,2,5

Outline Drawing

Electrical Specifications

REV. OR

M109914

ADE-R901+

ED-12872/3

WL/TD/CP

070516

A

B

C

D

E

F

G

.272

.310

.220

.100

.112

.055

.100

6.91

7.87

5.59

2.54

2.84

1.40

2.54

H

J

K

L

wt

.030

.026

.065

.300

grams

0.76

0.66

1.65

7.62

0.20

Typical Performance Data

Electrical Schematic

Operating Temperature

-40°C to 85°C

Storage Temperature

-55°C to 100°C

RF Power

50mW

IF Current

40mA

Features

• hermetically sealed ceramic quad

• low conversion loss, 5.9 dB typ.

• good L-R isolation, 38 dB typ.

• low profile package

• aqueous washable

• protected by US Patent 6,133,525

Applications

• cellular

• ISM/GSM

Frequency

(MHz)

Conversion

Loss

(dB)

Isolation

L-R

(dB)

Isolation

L-I

(dB)

VSWR

RF Port

(:1)

VSWR

LO Port

(:1)

RF

LO

LO

+7dBm

LO

+7dBm

LO

+7dBm

LO

+7dBm

LO

+7dBm

ADE-R901+

CASE STYLE: CD542

PRICE: $3.35 ea. QTY. (10-49)

291.24

321.24

6.20

47.77

41.40

1.73

2.96

331.44

361.44

6.11

46.70

40.45

1.62

2.98

391.75

421.75

5.94

45.70

38.98

1.51

2.92

431.96

461.96

5.87

44.86

38.09

1.44

2.95

492.27

522.27

5.81

43.80

36.31

1.38

2.94

532.47

562.47

5.84

43.52

35.60

1.33

2.95

592.78

622.78

5.83

42.64

34.24

1.29

2.95

632.99

662.99

5.87

42.11

33.30

1.24

2.93

693.30

723.30

5.84

41.41

32.25

1.21

2.91

733.51

763.51

5.88

40.94

31.42

1.15

2.89

793.81

823.81

5.89

39.97

30.05

1.10

2.91

800.00

830.00

5.84

39.69

28.77

1.13

2.96

850.00

880.00

5.86

38.93

28.14

1.03

2.97

880.00

910.00

5.87

38.60

27.71

1.05

3.02

900.00

930.00

5.86

38.47

27.46

1.06

3.01

940.00

970.00

5.77

38.06

27.07

1.10

3.01

950.00

980.00

5.77

38.13

27.08

1.10

3.03

970.00

1000.00

5.74

37.95

26.90

1.10

3.08

990.00

1020.00

5.74

37.75

26.65

1.14

3.13

1000.00

1030.00

5.70

37.75

26.52

1.18

3.13

+ RoHS compliant in accordance

with EU Directive (2002/95/EC)

The +Suffix has been added in order to identify RoHS

Compliance. See our web site for RoHS Compliance

methodologies and qualifications.
