1 dB COMP.: +5 dBm typ.

FREQUENCY

(MHz)

CONVERSION LOSS

(dB)

LO-RF ISOLATION

(dB)

LO-IF ISOLATION

(dB)

IP3

at center

band

(dBm)

LO/RF

IF

Max.

f

—

X

σ

Typ. Min.

Typ. Min.

Typ.

300-1000

DC-800

6.4

0.10

7.8

42 32

35 20

18

ISO 9001 ISO 14001 CERTIFIED

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site

The Design Engineers Search Engine Provides ACTUAL Data Instantly From MINI-CIRCUITS At: www.minicircuits.com

RF/IF MICROWAVE COMPONENTS

minicircuits.com

ALL NE

W

Page 1 of 2

PCB Land Pattern

Suggested Layout,

Tolerance to be within ±.002

Level 10 (LO Power +10 dBm) 300 to 1000 MHz

High Reliability Mixer

Surface Mount

Demo Board MCL P/N: TB-02

Suggested PCB Layout (PL-051)

Outline Dimensions (

)

inch

mm

Maximum Ratings

Pin Connections

LO

6

RF

4

IF

3

GROUND

1,2,5

Outline Drawing

Electrical Specifications

REV. OR

M109914

ADE-R901LH+

ED-12873/4

WL/TD/QL

070516

A

B

C

D

E

F

G

.272

.310

.220

.100

.112

.055

.100

6.91

7.87

5.59

2.54

2.84

1.40

2.54

H

J

K

L

wt

.030

.026

.065

.300

grams

0.76

0.66

1.65

7.62

0.20

Typical Performance Data

Electrical Schematic

Operating Temperature

-40°C to 85°C

Storage Temperature

-55°C to 100°C

RF Power

50mW

IF Current

40mA

Features

• hermetically sealed ceramic quad

• low conversion loss, 6.4 dB typ.

• excellent L-R isolation, 42 dB typ.

• low profile package

• aqueous washable

• protected by US Patent 6,133,525

Applications

• cellular

• ISM/GSM

Frequency

(MHz)

Conversion

Loss

(dB)

Isolation

L-R

(dB)

Isolation

L-I

(dB)

VSWR

RF Port

(:1)

VSWR

LO Port

(:1)

RF

LO

LO

+10dBm

LO

+10dBm

LO

+10dBm

LO

+10dBm

LO

+10dBm

ADE-R901LH+

CASE STYLE: CD542

PRICE: $3.35 ea. QTY. (10-49)

291.24

321.24

6.45

47.15

43.59

1.86

2.58

331.44

361.44

6.37

46.19

43.53

1.76

2.57

391.75

421.75

6.24

45.07

42.79

1.67

2.50

431.96

461.96

6.19

44.03

42.11

1.61

2.50

492.27

522.27

6.11

43.64

40.26

1.57

2.49

532.47

562.47

6.20

43.05

39.91

1.52

2.49

592.78

622.78

6.11

42.54

37.39

1.51

2.50

632.99

662.99

6.19

42.06

36.09

1.47

2.48

693.30

723.30

6.27

41.77

35.79

1.47

2.52

733.51

763.51

6.44

41.51

34.44

1.44

2.52

793.81

823.81

6.47

41.27

32.97

1.44

2.58

834.02

864.02

6.44

41.24

31.75

1.42

2.58

894.33

924.33

6.42

40.57

30.76

1.40

2.63

994.85

1024.85

6.40

41.22

31.23

1.33

2.77

1035.05

1065.05

6.44

41.30

30.42

1.29

2.83

+ RoHS compliant in accordance

with EU Directive (2002/95/EC)

The +Suffix has been added in order to identify RoHS

Compliance. See our web site for RoHS Compliance

methodologies and qualifications.
