Top V iew

Side View

B ottom V iew

R ecom m ended P ad Layout

Schem atic

1

2

1

2

6.80 M ax

6.80 M ax

3.3±0.3

H C P 0704-R 40 to 2R 3= 1.20 +/- 0.2

H C P 0704-3R 3 to 4R 7= 1.00 +/- 0.2

H C P 0704-R 40 to 1R 0= 4.20 m ax

H C P 0704-1R 8 to 4R 7= 4.00 m ax

7.60

2.50(2x)

4.00(2x)

2

1

D

Diim

me

en

ns

siio

on

ns

s -- m

mm

m

User direction of feed

HCP0704-R40 to 1R0= 4.2

HCP0704-1R8 to 4R7= 4.0

Section A-A

1.5 Dia

min.

7.50

6.9

12.0

4.0

2.0

1.5 Dia.

+0.1/-0.0

A

A

1.75

7.5

16.0

±0.3

1

2

HCP0704

wwllyy R

xxx

0

10

20

30

40

50

60

0

0.2

0.4

0.6

0.8

1

1.2

1.4

Tota l Los s (W)

Part Marking: HCP0704

xxx = Inductance value in

μH. (R = Decimal point). If no “R” is present, then last character is # of zeros

wwllyy = Date code

R = Revision level

The nominal DCR test point is in the middle of the terminal

Supplied in tape-and-reel packaging, 1000 parts per reel, 13” diameter reel.

Packaging Information - mm

Temperature Rise vs. Total Loss

0209

BU-SB09086

Page 2 of 4

Data Sheet: 4348
