Dimensions - mm

A = 11.0 Max.

B = 8.0 Max.

C = 4.9 Max.

D = 2.4 ± 0.2

E = 2.3 ± 0.3

F = 6.2 Typ.

1

2

wwllyy

B

A

E

F

Top View

Bottom View

Left View

2.8

2.8

5.8

Rxx

1

2

a

b

Recommended Pad Layout

Schematic

C

D

1105Rx

R

SECTION A-A

A

A

1.5 dia

1.5 dia

4.0

2.0

12.0

1.75

11.5

24.0

+/-0.3

User direction of feed

1

2

8.2

wwllyy

Rxx

5.2

11.3

1105Rx

R

0

10

20

30

40

50

0

0.2

0.4

0.6

0.8

1

1.2

1.4

1.6

Total loss (W)

Part Marking: Coiltronics Logo

1105Rx (Rx = DCR indicator)

Rxx = inductance value in

μH (R = decimal point)

wwllyy = date code

R = revision level

Supplied in tape-and-reel packaging, 900 parts per reel, 13” diameter reel.

Packaging Information - mm

Temperature Rise vs.Total Loss

05-05-08

BU-SB08211

Page 2 of 4

Data Sheet: 4324

Nominal DCR is measured from point “a” to point “b.”
