Dimensions - mm

A = 7.0 Max.

B = 7.0 Max.

C = 4.95 Max.

D = 2.45 ± 0.2

E = 1.52 ± 0.2

F = 3.5 Typ.

Top View

a

b

B

A

E

D

F

1

2

Rxx

wwllyy

Side View

Bottom View

2.0

3.1

3.3

Recommended Pad Layout

Schematic

1

2

C

0705Rx

R

SECTION A-A

A

A

5.1

7.1

7.1

User direction of feed

1

2

SECTION B-B

B

B

6.5

3.5

Rxx

wwllyy

0705Rx

R

16.00

±0.30

1.5

dia.

12.0

1.5

dia

7.5

1.75

4.0

2.0

0

20

40

60

80

0.0

0.2

0.4

0.6

0.8

1.0

1.2

Total Loss (W)

Part Marking: Coiltronics Logo

0705Rx (Rx = DCR indicator)

Rxx = inductance value in

μH (R = decimal point)

wwllyy = date code

R = revision level

Supplied in tape-and-reel packaging, 950 parts per reel, 13” diameter reel.

Nominal DCR is measured from point “a” to point “b.”

Packaging Information - mm

Temperature Rise vs. Total Loss

05-05-08

BU-SB08210

Page 2 of 4

Data Sheet: 4325
