Top V iew

S ide V iew

R ecom m ended P ad Layout

Schem atic

1

2

2.5 nom .

(2x)

1

2

3.0

(2X )

3.0

(2X )

11.4

11.2

max

11.2 m ax

9.0

max

4.10 ref

(2X )

2.03 ref

Front V iew

D

Diim

me

en

ns

siio

on

ns

s -- m

mm

m

Section A-A

9.3

1.5 dia. +0.1/-0.0

1.5 dia. min

4.00

2.00

20.00

1.75

11.50

24.0 ±0.3

User direction of feed

11.4

11.4

1

2

16.4

17.5

2.0

0

10

20

30

40

50

0

0.2

0.4

0.6

0.8

1

1.2

1.4

1.6

T otal Loss (W )

Part Marking: FP1109

xxx = Inductance value in

μH. (R = Decimal point). If no “R” is present, then last character is # of zeros

wwllyy = Date code

R = Revision level

Supplied in tape-and-reel packaging, 350 parts per reel, 13” diameter reel.

Packaging Information - mm

Temperature Rise vs.Total Loss

1108

BU-SB08800

Page 2 of 4

Data Sheet: 4350
