Applications

• Multi-phase regulators

• Voltage Regulator Module (VRM)

• Desktop and server VRMs and EVRDs

• Data networking and storage systems

• Notebook regulators

• Graphics cards and battery power systems

• Point-of-load modules

• DCR sensing

Environmental Data

• Storage temperature range: -40°C to +125°C

• Operating temperature range: -40°C to +125°C

(with derated current)

• Solder reflow temperature: J-STD-020D compliant

Packaging

• Supplied in tape and reel packaging, 400 parts per reel,

13” diameter reel

HALOGEN

HF

FREE

Description

• Halogen Free

• 125°C maximum total temperature operation

• 12.70 x 13.46 x 8.0mm surface mount package

• Ferrite core material

• High current carrying capacity, Low core losses

• Controlled DCR tolerance for sensing circuits

• Inductance range from 110nH to 440nH

• Current range from 37 to 120 Amps

• Frequency range up to 2MHz

• RoHS compliant

High Current, High Frequency, Power Inductors

FLAT-PAC™ FP1308R Series

0209

BU-SB08890

Page 1 of 4

Data Sheet: 4355

SMD Device

1 Open Circuit Inductance (OCL) Test Parameters: 100kHz, 0.10Vrms, 0.0Adc

2 Full Load Inductance (FLL) Test Parameters: 100kHz, 0.1Vrms,Isat1.

3Irms: DC current for an approximate temperature rise of 40°C without core loss. Derating is

necessary for AC currents. PCB pad layout, trace thickness and width, air-flow and proximity of

other heat generating components will affect the temperature rise. It is recommended the part

temperature not exceed 125°C under worst case operating conditions verified in the end

application.

4Isat: Peak current for approximately 20% rolloff at +25°C.

5 Isat2: Peak current for approximately 20% rolloff at +125°C.

6 K-factor: Used to determine Bp-p for core loss (see graph). Bp-p = K * L * ΔI * 10

K: (K-factor from table), L: (inductance in nH),

ΔI (peak-to-peak ripple current in amps).

7 Part Number Definition: FP1308Rx-Rxx-R

• FP1308 = Product code and size

• Rx = DCR indicator

• Rxx = Inductance value in

μH, R = decimal point.

• “-R” suffix = RoHS compliant

Product Specifications

Part

OCL

1

FLL

2

Irms

3

Isat1

4

Isat2

5

DCR (m

Ω)

Number

7

± 10% (nH)

(nH)

(Amps)

@ 25°C (Amps)

@ 125°C (Amps)

@ 20°C

K-factor

6

R1 Version

FP1308R1-R11-R

110

79

120

105

233

FP1308R1-R21-R

210

152

80

68

233

FP1308R1-R26-R

260

187

57

64

52

0.32 ± 9.4%

233

FP1308R1-R32-R

320

230

52

40

233

FP1308R1-R44-R

440

317

37

28

233

R2 Version

FP1308R2-R11-R

110

79

120

105

233

FP1308R2-R21-R

210

152

80

68

233

FP1308R2-R26-R

260

187

45

64

52

0.53 ± 10%

233

FP1308R2-R32-R

320

230

52

40

233

FP1308R2-R44-R

440

317

37

28

233

R3 Version

FP1308R3-R11-R

110

79

120

105

233

FP1308R3-R21-R

210

152

80

68

233

FP1308R3-R26-R

260

187

68

64

52

0.18 ± 20%

233

FP1308R3-R32-R

320

230

52

40

233

FP1308R3-R44-R

440

317

37

28

233
