Elektronische Bauelemente

SPWLM393D

Comparator

Dual Differential

* Low Input Bias Current Ibias=25nA(Typ.)

Output Compatible With TTL, DTL, and CMOS Logic System

* Low Supply Current Drain ICC=0.8mA(Typ.)

* Single Or Dual Supply Operation

Input Common-Mode Voltage Range Includes Ground

Features

*

*

The SPWLM393D consists of two independent voltage comparators,

designed specifically to operate from a single power over a wide

voltage range.

Description

01-Jun-2002 Rev. A

Page 1 of 4

http://www.SeCoSGmbH.com/

Any changing of specification will not be informed individual

RoHS Compliant Product

SEATING PLANE

e

b

Z

Z

D

SECTION Z - Z

b

GAUGE PLANE

DIP-8

Millimeter

Millimeter

REF.

Min.

Max.

REF.

Min.

Max.

A

-

0.5334

c1

0.203

0.279

A1

0.381

-

D

9.017

10.16

A2

2.921

4.953

E

6.096

7.112

b

0.356

0.559

E1

7.620

8.255

b1

0.356

0.508

e

2.540 BSC

b2

1.143

1.778

HE

-

10.92

b3

0.762

1.143

L

2.921

3.810

c

0.203

0.356

rogrammed by

pacitor CT to ground .Operation 500kHz

nts up to

This is the reference output .It provides charging current for capacitor CT

±

±

Pin Configurations

Block Diagram
