Conformal Coated Inductors - Axial

ctparts.com

Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids

800-684-5322 Inside US

949-453-1811 Outside US

Copyright © 2005 by CT Magnetics, DBA Central Technologies. All rights reserved.

CT Magnetics reserves the right to make improvements or change specifications without notice

CENTRAL

12.12.05

Size

A

B

C

24 AWG

mm

3.4

2.2 ± 0.2

26.6

0.5110

inches

0.135

0.09 ± 0.01

1.05

0.2010

PHYSICAL DIMENSIONS

SPECIFICATIONS

Please specify tolerance code when ordering.

CTC0F-R22_

J = ±5%, K = ±10%, M = ±20%

L Test

Q

Q Test

SRF

DCR

Rated

Part

Inductance

Freq.

Factor

Freq.

Min.

Max.

DC

Number

(µH)

(MHz)

Min.

(MHz)

(MHz)

(

Ω

Ω)

(mA)

CTC0F-R22_

.22

25.2

42

25.2

150

.40

400

CTC0F-R27_

.27

25.2

42

25.2

150

.43

380

CTC0F-R33_

.33

25.2

42

25.2

150

.48

370

CTC0F-R39_

.39

25.2

42

25.2

150

.51

350

CTC0F-R47_

.47

25.2

42

25.2

150

.56

330

CTC0F-R56_

.56

25.2

42

25.2

150

.61

320

CTC0F-R68_

.68

25.2

50

25.2

150

.67

310

CTC0F-R82_

.82

25.2

50

25.2

150

.71

290

CTC0F-1R0_

1.0

25.2

50

25.2

150

.80

270

CTC0F-1R2_

1.2

7.96

50

7.96

110

.90

260

CTC0F-1R5_

1.5

7.96

50

7.96

80

1.00

250

CTC0F-1R8_

1.8

7.96

50

7.96

80

1.10

240

CTC0F-2R2_

2.2

7.96

50

7.96

45

1.20

230

CTC0F-2R7_

2.7

7.96

50

7.96

40

1.30

220

CTC0F-3R3_

3.3

7.96

55

7.96

38

1.40

210

CTC0F-3R9_

3.9

7.96

55

7.96

35

1.60

200

CTC0F-4R7_

4.7

7.96

55

7.96

32

1.70

190

CTC0F-5R6_

5.6

7.96

55

7.96

30

1.90

180

CTC0F-6R8_

6.8

7.96

55

7.96

28

2.00

175

CTC0F-8R2_

8.2

7.96

55

7.96

26

2.20

165

CTC0F-100_

10

7.96

55

7.96

24

2.50

160

CTC0F-120_

12

2.52

55

2.52

22

2.50

150

CTC0F-150_

15

2.52

55

2.52

20

2.80

145

CTC0F-180_

18

2.52.

55

2.52

18

3.10

140

CTC0F-220_

22

2.52

55

2.52

17

3.40

130

CTC0F-270_

27

2.52

55

2.52

16

4.30

80

CTC0F-330_

33

2.52

55

2.52

14

4.70

76

CTC0F-390_

39

2.52

55

2.52

13

5.20

74

CTC0F-470_

47

2.52

55

2.52

12

5.80

70

CTC0F-560_

56

2.52

55

2.52

11

6.40

68

CTC0F-680_

68

2.52

55

2.52

10

7.20

64

CTC0F-820_

82

2.52

55

2.52

9.5

11.0

46

CTC0F-101_

100

.796

55

.796

9.0

12.0

44

CTC0F-121_

120

.796

55

.796

8.0

13.0

43

CTC0F-151_

150

.796

55

.796

6.0

16.0

40

CTC0F-181_

180

.796

55

.796

5.5

18.0

38

CTC0F-221_

220

.796

55

.796

5.0

20.0

35

CTC0F Series

From .22 µH to 220 µH

Not shown at actual size.

CHARACTERISTICS

Description: Axial leaded conformal coated inductor

Applications: Used in less harsh environments. Ideal for less

critical RFL/EMI applications

Operating Temperature: -55°C to +125°C

Inductance Tolerance: ±5%, ±10%, ±20%

Testing: Inductance and Q are tested on an HP4285A at

specified frequency

Packaging: Bulk,1000 pieces per bag, Tape & Reel - 5000 pieces

per reel

Material: Magnetic core treated with epoxy resin for protection

and longer reliability

Marking: Parts are EIA three color banded indicating inductance

value and tolerance

Additional Information: Additional electrical & physical

information available upon request

Samples available. See website for ordering information.

RoHS

Compliant
