Power Inductors - Shielded

ctparts.com

Manufacturer of Passive Components

800-684-5322 Inside US

949-453-1811 Outside US

Copyright © 2008 by CT Magnetics, DBA Central Technologies. All rights reserved.

CT Magnetics reserves the right to make improvements or change specifications without notice

CENTRAL

TECHNOLOGIES

09.16.08

SPECIFICATIONS

Parts are only available ±20% inductance tolerance only

L Test

*Irms

**Isat

DCR

Part

Inductance

Freq.

Typ.

Typ.

Max.

Number

(µH)

(KHz)

(A)

(A)

(m

Ω

Ω)

CTIHLP104F-R36M

0.36

100

34

42

1.2

CTIHLP104F-R45M

0.45

100

33

38

1.2

CTIHLP104F-R47M

0.47

100

33

38

1.2

CTIHLP104F-R50M

0.50

100

27

32

1.55

CTIHLP104F-R56M

0.56

100

27

32

1.55

CTIHLP104F-R68M

0.68

100

27

30

1.55

CTIHLP104F-R88M

0.88

100

20

27

3.1

CTIHLP104F-1R0M

1.00

100

20

26

3.1

CTIHLP104F-2R5M

2.50

100

13

13

6.8

CTIHLP104F Series

From .36 µH to 2.5 µH

Not shown at actual size.

CHARACTERISTICS

Description: SMD (shielded) power inductor

Applications: High density DC/DC converters. POL converters.

High current VRM/VRD for notebooks, Servers, and desktop

CPUs. High speed chargers.

Operating Temperature: -55°C to +125°C

Inductance Tolerance: ±20%

Testing: Inductance is tested on an HP4285A at 100KHz, 0.5V

Packaging: Tape & Reel

Marking: Parts are marked with inductance code

Additional Information: Additional electrical & physical

information available upon request

Samples available. See website for ordering information.

PHYSICAL DIMENSIONS

RECOMMENDED LAND PATTERN

A

B

D

C

XXX

Marking: Inductance Code

4.0

9.5

3.5

Unit: mm

RoHS

Compliant

*Irms DC current (A) will cause an approximately

ΔT of 40°C.

**Isat DC current (A) will cause L0 to drop approximately 20%.

Size

A

B

C

D

Max.

Max.

Typ.

mm

10.1±0.3

11.6

4.0

3.0

inches

0.39±0.01

0.46

0.15

0.12
