Multi-layer Chip Inductors - Ferrite

ctparts.com

Manufacturer of Passive and Discrete Semiconductor Components

800-684-5322 Inside US

949-453-1811 Outside US

Copyright © 2008 by CT Magnetics, DBA Central Technologies. All rights reserved.

CT Magnetics reserves the right to make improvements or change specifications without notice

CENTRAL

04.11.08

Size

A

B

C

D

mm

1.6±0.15

0.8±0.15

0.8±0.15

0.3±0.2

inches

0.06±0.006

0.03±0.006

0.03±0.006

0.01±0.008

PHYSICAL DIMENSIONS

SPECIFICATIONS

Please specify tolerance code when ordering.

CTML0603-R047_

K = ±10%, M = ±20%

CTML0603F Please specify “F” for RoHS Compliant

L Test

Q

Q Test

SRF

DCR

Rated

Part

Inductance

Freq.

Factor

Freq.

Min.

Max.

DC

Number

(µH)

(MHz)

Min.

(MHz)

(MHz)

(

Ω

Ω)

(mA)

CTML0603_-R047_

.047

50

10

50

260

.30

50

CTML0603_-R068_

.068

50

10

50

250

.30

50

CTML0603_-R082_

.082

50

10

50

245

.30

50

CTML0603_-R10_

.10

25

15

25

240

.50

50

CTML0603_-R12_

.12

25

15

25

205

.50

50

CTML0603_-R15_

.15

25

15

25

180

.60

50

CTML0603_-R18_

.18

25

15

25

165

.60

50

CTML0603_-R22_

.22

25

15

25

150

.80

50

CTML0603_-R27_

.27

25

15

25

136

.80

50

CTML0603_-R33_

.33

25

15

25

125

.85

35

CTML0603_-R39_

.39

25

15

25

110

1.0

35

CTML0603_-R47_

.47

25

15

25

105

1.3

35

CTML0603_-R56_

.56

25

15

25

95

1.5

35

CTML0603_-R68_

.68

25

15

25

90

1.7

35

CTML0603_-R82_

.82

25

15

25

85

2.1

35

CTML0603_-1R0_

1.0

10

35

10

75

.60

25

CTML0603_-1R2_

1.2

10

35

10

65

.80

25

CTML0603_-1R5_

1.5

10

35

10

60

.80

25

CTML0603_-1R8_

1.8

10

35

10

55

.95

25

CTML0603_-2R2_

2.2

10

35

10

50

1.1

15

CTML0603_-2R7_

2.7

10

35

10

45

1.3

15

CTML0603_-3R3_

3.3

10

35

10

40

1.5

15

CTML0603_-3R9_

3.9

10

35

10

35

1.7

15

CTML0603_-4R7_

4.7

10

35

10

33

2.1

15

CTML0603_-5R6_

5.6

4

35

4

22

1.5

5

CTML0603_-6R8_

6.8

4

35

4

20

1.7

5

CTML0603_-8R2_

8.2

4

35

4

18

2.1

5

CTML0603_-100_

10

2

30

2

17

1.8

3

CTML0603_-120_

12

2

30

2

15

2.1

3

CTML0603_-150_

15

1

20

1

14

1.7

1

CTML0603_-180_

18

1

20

1

13

1.8

1

CTML0603_-220_

22

1

20

1

11

2.1

1

CTML0603_-270_

27

1

20

1

10

2.7

1

CTML0603_-330_

33

1

20

1

9

2.9

1

CTML0603 Series

From .047 µH to 33 µH

Not shown at actual size.

CHARACTERISTICS

Description: Ferrite core, multi-layer chip inductor. Magnetic

shielded.

Applications: LC resonant circuits such as oscillator and signal

generators, RF filters, disk drives, audio and video equipment, TV,

radio and telecommunication equipment

Operating Temperature: -55°C to +125°C

Inductance Tolerance: ±10% & ±20%

Testing: Inductance and Q are tested on an HP4286A at

specified frequency

Packaging: Tape & Reel

Marking: Reels marked with inductance code and tolerance

Additional Information: Additional electrical & physical

information available upon request

Samples available. See website for ordering information.

PAD LAYOUT

ENGINEERING KIT #17
