Features

Condition

Min

Typ

Max

Unit

Optical Performance

Wavelength

T= 25°C

635

nm

Output Power

T= 25°C

20

mW

Noise(RMS)

10~20 MHz

0.1

0.3

%

Power Stability

1hrs, T= 25°C

0.25

0.5

%

Power Stability

24hrs, T= 25°C

0.75

1

%

Polarization Extinction Ratio

15

dB

Collimated Beam Parameters

M2

1.2

Beam Diameter

1/e2

0.7, 0.9, 1.5, 2.0, 4.0, 6.0

mm

Beam Divergence

full angle

1

mrad

Pointing Stability

2hrs, T= 25°C

5

urad

Pointing Stability

1

urad/°C

Fiber Information

Length

1, 2, 3

m

Fiber Type

SM / PM

Mode Field Diameter

3

um

NA

0.12

Fiber Jacket Diameter

3

mm

Electrical Parameters

Power Supply

9

V

Power Consumption

3

10

W

Current(TEC)

2

A

Current(LD)

200

mA

Temperature Stability

0.2

°C

Control

ACC

Power Setting

0% ~ 100% output power

Environmental Conditions

Storage Temperature

0 to + 50

°C

Operation Temperature

+ 10 to + 40

°C

Operation Humidity

No Condensing

112 x 56 x 26.5

mm

Applications

Note:

* The mechanical tolerance should be +/-0.2

mm on all package dimensions unless otherwise

custom specified.

R04.20090331

FCLM635 Series

with excellent beam pointing stability at a wide temperature dynamic range.The

unique designed electrical driver enable this optical engine has the lowest power

Module is a Class III b laser product



Plug & Play



ESD Protection



Power Adjustable



LD Current Full Protection



LD Temperature Stabilized



Compact Size



Polarization Maintaining Fiber



High Speed Modulation



Remote Control



Collimated & Focused Beam



Metal Jacket Protection
