PCS3P73U00A

rev 0.3

USB 2.0 Peak EMI reduction IC

3 of 13

Notice: The information in this document is subject to change without notice.

Absolute Maximum Rating

Symbol

Parameter

Rating

Unit

Voltage on any pin with respect to Ground

-0.5 to +4.6

V

Storage temperature

-65 to +125

°C

Max. Soldering Temperature (10 sec)

260

°C

Junction Temperature

150

°C

Static Discharge Voltage (As per JEDEC STD22- A114-B)

2

KV

Note: These are stress ratings only and are not implied for functional use. Exposure to absolute maximum ratings for prolonged periods of time may affect

device reliability.

Operating Conditions

Parameter

Description

Min

Max

Unit

Supply Voltage

3.0

3.6

V

Supply Voltage

2.3

2.7

V

Operating Temperature (Ambient Temperature)

0

+70

°C

Load Capacitance

10

pF

Input Capacitance

7

pF

Electrical Characteristics for 3.3V Supply voltage

Parameter

Description

Test Conditions

Min

Typ

Max

Unit

Supply Voltage

3.0

3.3

3.6

V

Input LOW Voltage

0.8

V

Input HIGH Voltage

2.0

V

Input LOW Current

-50

µA

Input HIGH Current

50

µA

Output LOW Voltage

0.4

V

Output HIGH Voltage

2.4

V

Static Supply Current

XIN / CLKIN pulled to GND

750

µA

FS=0; @ 12MHz

8

Dynamic Supply Current

Unloaded outputs

FS=1; @ 48MHz

12

mA

Output Impedance

30

Ω
