PS0804 , PS0805 , PS1003 ,

SMD Power Inductors Shielded

C/Severo Ochoa 33 – Parque Tecnológico de Andalucía. 29590 Campanillas .Málaga (Spain)

Phone +34 951 231 320 Fax +34 951 231 321

E-mail: mar.villarrubia@grupopremo.com Web http://www.grupopremo.com

SMD Power Inductors

P

R

RE

M

MO

O

O

All rights reserved. Passing on of this document, use and communication of contents not permitted without written authorisation.

10

9. Reliability Test

Test item

Specification

Test condition

Solderability

More than 90% of the

terminal electrode

shall be covered

with fresh solder

Preheat : 150±25% for 60 seconds

Solder : Sn96.5 / Ag3 / Cu0.5 or equivalent

Flux : Rosin

Dip time : 4±1 seconds

Thermal shock test

(Temp. cycle)

Room temp.

-25±2ºC

15 minutes

30 minutes

Room temp.

85±2ºC

15 minutes

30 minutes

Total : 50 cycles

Humidity

Resistance test

Temperature : 40±2ºC

Humidity : 90 ~ 95%

Applied current : Per specifications

Time : 500 hours

High temp.

Resistance test

Inductance shall

not change more

than ±20%

Temperature : 105±2ºC

Applied current : Per specifications

Time : 500 hours

10. Edition Control

Edition

Date

Change description

Made by

31/08/06

Update Specification

Pablo Pozo
