557-175

D-Subminiature G-Spring Solid Backshell

1. Metric dimensions (mm) are indicated in parentheses.

2. DO NOT USE CONNECTORS WITH FLOAT MOUNTINGS.

3. For front mount, mating connector must be mounted to panel using

M24308/26 female screwlocks. For rear mount, use Glenair GK134.

4. For proper termination it is recommended that Glenair 469-001 shield

support ring be used on all assemblies. Place ring over wire bundle and

under shield, position under G-Spring.

Min

.125

(3.2)

.156

(4.0)

.280

(7.1)

.280

(7.1)

.375

(9.5)

.625 (15.9)

Cable Range

Max

.250

(6.4)

.375

(9.5)

.500 (12.7)

.500 (12.7)

.625 (15.9)

.875 (22.2)

Shell

Size

1

2

3

4

5

6

TABLE I (Continued): CABLE ENTRY & GLAND NUT

Com’l

Shell

Size Ref

E/09

A/15

B/25

C/37

D/50

F/104

F

Max

.625 (15.9)

.750 (19.1)

1.000 (25.4)

1.000 (25.4)

1.250 (31.8)

1.375 (34.9)

E

Max

.843 (21.4)

.968 (24.6)

1.156 (29.4)

1.156 (29.4)

1.218 (30.9)

1.468 (37.3)

Dash

No.

01

02

03

04

05

06

07

08

09

10

TABLE III: SUPPORT RING

I.D.

.187

(4.7)

.218

(5.5)

.250

(6.4)

.281

(7.1)

.312

(7.9)

.343

(8.7)

.375

(9.5)

.406 (10.3)

.438 (11.1)

.468 (11.9)

O.D.

.227

(5.8)

.258

(6.6)

.290

(7.4)

.321

(8.2)

.352

(8.9)

.383

(9.7)

.415 (10.5)

.446 (11.3)

.478 (12.1)

.508 (12.9)

Inner Support

Dash

No.

R1

R2

R3

R4

R5

R6

R7

R8

F0

TABLE II: RECEPTACLE MOUNTING

Panel

Thickness

.031

(.8)

.047

(1.2)

.062

(1.6)

.093

(2.4)

.104

(2.6)

.125

(3.2)

.156

(4.0)

.135

(3.4)

N/A

G

.247

(6.3)

.231

(5.9)

.216

(5.5)

.185

(4.7)

.174

(4.4)

.153

(3.9)

.125

(3.2)

.140

(3.6)

.305

(7.7)

Shell

Size

1

2

3

4

5

6

TABLE I: SHELL SIZE & CONNECTOR INTERFACE DIMENSIONS

Com’l

Shell Size

Ref

E/09

A/15

B/25

C/37

D/50

F/104

A

1.241 (31.5)

1.569 (39.9)

2.116 (53.7)

2.757 (70.0)

2.663 (67.6)

2.757 (70.0)

B

.515 (13.0)

.515 (13.0)

.515 (13.0)

.515 (13.0)

.625 (15.9)

.688 (17.5)

C

.258

(6.6)

.258

(6.6)

.258

(6.6)

.258

(6.6)

.313

(8.0)

.344

(8.7)

D

±.005

(.1)

.984 (25.0)

1.312 (33.3)

1.852 (47.0)

2.500 (63.5)

2.406 (61.1)

2.500 (63.5)
