VRE3025

6

VRE3025DS

6. ThERMal hYSTERISIS

A change in output voltage as a result of a temperature change. When references experience a temperature change

and return to the initial temperature, they do not always have the same initial voltage. Thermal hysterisis is difficult to

correct and is a major error source in systems that experience temperature changes greater than 25°C. Reference

vendors are starting to include this important specification in their datasheets.

PIN CONFIGuRaTION

0.01

0.1

1

10

100

1000

10000

0

0

1

0

1

1

20 BIT

18 BIT

16 BIT

14 BIT

12 BIT

10 BIT

8 BIT

Reference TC vs. ∆T change from 25°C for 1 LSB change

5

6

7

8

VRE3025

TOP

VIEW

1

2

3

4

N/C

N/C

GND

NOISE

REDUCTION

TRIM

N/C
