OUTLINE DIMENSIONS

NOTES:

1. DIMENSION L TO CENTER OF LEAD WHEN

FORMED PARALLEL.

2. PACKAGE CONTOUR OPTIONAL (ROUND OR

SQUARE CORNERS).

3. DIMENSIONING AND TOLERANCING PER ANSI

Y14.5M, 1982.

14

5

8

F

NOTE 2

–A–

–B–

–T–

SEATING

PLANE

H

J

G

D

K

N

C

L

M

M

A

M

0.13 (0.005)

T

DIM

MIN

MAX

MIN

MAX

INCHES

MILLIMETERS

A

9.40

10.16

0.370

0.400

B

6.10

6.60

0.240

0.260

C

3.94

4.45

0.155

0.175

D

0.38

0.51

0.015

0.020

F

1.02

1.78

0.040

0.070

G

2.54 BSC

0.100 BSC

H

0.76

1.27

0.030

0.050

J

0.20

0.30

0.008

0.012

K

2.92

3.43

0.115

0.135

L

7.62 BSC

0.300 BSC

M

–––

10

–––

10

N

0.76

1.01

0.030

0.040

__

D SUFFIX

PLASTIC PACKAGE

CASE 751–05

(SO–8)

ISSUE R

N SUFFIX

PLASTIC PACKAGE

CASE 626–05

ISSUE K

SEATING

PLANE

1

4

5

8

A

h

q

C

X 45

_

L

DIM

MIN

MAX

MILLIMETERS

A

1.35

1.75

A1

0.10

0.25

B

0.35

0.49

C

0.18

0.25

D

4.80

5.00

E

1.27 BSC

e

3.80

4.00

H

5.80

6.20

h

0

7

L

0.40

1.25

q

0.25

0.50

_

_

NOTES:

1. DIMENSIONING AND TOLERANCING PER ASME

Y14.5M, 1994.

2. DIMENSIONS ARE IN MILLIMETERS.

3. DIMENSION D AND E DO NOT INCLUDE MOLD

PROTRUSION.

4. MAXIMUM MOLD PROTRUSION 0.15 PER SIDE.

5. DIMENSION B DOES NOT INCLUDE MOLD

PROTRUSION. ALLOWABLE DAMBAR

PROTRUSION SHALL BE 0.127 TOTAL IN EXCESS

OF THE B DIMENSION AT MAXIMUM MATERIAL

CONDITION.

D

E

H

A

B

e

B

A1

C

A

0.10
