MODEL

LEP100F-24

LEP100F-36

LEP100F-48

DC OUTPUT

+24V 4.2(Peak 7)A

+36V 2.8(Peak 4.7)A

+48V 2.1(Peak 3.5)A

SPECIFICATIONS

MODEL

LEP100F-24

LEP100F-36

LEP100F-48

INPUT

VOLTAGE[V]

AC85 - 264 1

f or DC 120 - 370

CURRENT[A]

ACIN 100V 1.4typ (Io=100%)

ACIN 200V 0.7typ (Io=100%)

FREQUENCY[Hz]

50/60 (47-63) or DC

EFFICIENCY[%]

ACIN 100V 81typ (Io=100%)

82typ (Io=100%)

83typ (Io=100%)

ACIN 200V 84typ (Io=100%)

85typ (Io=100%)

POWER FACTOR

ACIN 100V 0.98typ (Io=100%)

ACIN 200V 0.93typ (Io=100%)

INRUSH CURRENT[A]

ACIN 100V 15typ (Io=100%)(At cold start)(Ta=25

C)

ACIN 200V 30typ (Io=100%)(At cold start)(Ta=25

C)

LEAKAGE CURRENT[mA]

0.75max (60Hz, According to IEC60950 and DEN-AN)

OUTPUT

VOLTAGE[V]

+24

+36

+48

CURRENT[A]

*2 0 - 4.2 (Peak 7)

0 - 2.8 (Peak 4.7)

0 - 2.1 (Peak 3.5)

WATTAGE[W]

100.8 (Peak 168)

100.8 (Peak 169.2)

100.8 (Peak 168)

LINE REGULATION[mV]

48max

LOAD REGULATION[mV]

76max

90max

150max

RIPPLE[mVp-p]

0to+50

C*3 120max

120max

150max

-10-0

C*3 160max

160max

300max

RIPPLE NOISE[mVp-p]

0to+50

C*3 150max

150max

250max

-10-0

C*3 180max

180max

350max

TEMPERATURE REGULATION[mV]

0to+50

C 120max

150max

240max

-10 to +50

C 145max

180max

300max

DRIFT[mV]

*4 48max

48max

START-UP TIME[ms]

500max (ACIN 100V, Io=100%)

HOLD-UP TIME[ms]

20typ (ACIN 100V, Io=100%)

OUTPUT VOLTAGE ADJUSTMENT RANGE[V]

21.4 - 26.4

26.4 - 39.6

39.6 - 52.8

OUTPUT VOLTAGE SETTING[V]

23.0 - 25.0

35.0 - 37.0

46.0 - 50.0

PROTECTION

CIRCUIT AND

OTHERS

OVERCURRENT PROTECTION

Works over 101% of peak current and recovers automatically

OVERVOLTAGE PROTECTION

Works at 115 - 140% of rating

REMOTE ON/OFF

Option (Refer to Instruction Manual)

ISOLATION

INPUT-OUTPUT

-RC

*5 AC3,000V 1minute, Cutoff current = 10mA, DC500V 50M

W min (At Room Temperature)

INPUT-FG

AC2,000V 1minute, Cutoff current = 10mA, DC500V 50M

W min (At Room Temperature)

OUTPUT

-RC-FG

*5 AC500V 1minute, Cutoff current = 100mA, DC500V 50M

W min (At Room Temperature)

OUTPUT-RC

*5 AC100V 1minute, Cutoff current = 100mA, DC100V 10M

W min (At Room Temperature)

ENVIRONMENT

OPERATING TEMP.,HUMID.AND ALTITUDE

-10 to +70

C, 20 - 90%RH (Non condensing)(Refer to DERATING CURVE), 3,000m (10,000feet) max

STORAGE TEMP.,HUMID.AND ALTITUDE

-20 to +75

C, 20 - 90%RH (Non condensing), 9,000m (30,000feet) max

VIBRATION

10 - 55Hz, 19.6m/s2 (2G), 3minutes period, 60minutes each along X, Y and Z axis

IMPACT

196.1m/s2 (20G), 11ms, once each X, Y and Z axis

SAFETY AND

NOISE

REGULATIONS

AGENCY APPROVALS

UL60950-1, C-UL(CSA60950-1), EN60950-1, EN50178 Complies with DEN-AN and IEC60950-1 (At only AC input)

CE MARKING

Low Voltage Directive, EMC Directive

CONDUCTED NOISE

Complies with FCC-B, CISPR22-B, EN55022-B, VCCI-B

HARMONIC ATTENUATOR

Complies with IEC61000-3-2

OTHERS

CASE SIZE/WEIGHT

75

X35X222mm (WXHXD) /380g max (without chassis and cover)

COOLING METHOD

Convection

*1 Specification is changed at option, refer to Instruction Manual 6.

*2 Peak loading for 10sec. And Duty 35% max, refer to Instruction Manual 5. In detail.

*3 This is the value that measured on measuring board with capacitor of 22mF within 150mm

from output terminal.Measured by 20MHz oscilloscope or Ripple-Noise meter (Equivalent to

KEISOKU-GIKEN: RM101).

*4 Drift is the change in DC output for an eight hour period after a half-hour warm-up at 25C,

with the input voltage held constant at the rated input/output.

*5 Applicable when remote control (optional) is added.

* Parallel operation with other model is not possible.

* Derating is required when operated with chassis and cover.

* A sound may occur from power supply at peak loading.

LEP100F

Rugged PCB type

LEP 100

F

-24

-

O

Ordering information

1Series name

2Output wattage

3Universal input

4Output voltage

5Optional *1

G :Low leakage current

R :with Remote ON/OFF

S :with Chassis

SN:with Chassis & cover

T :Vertical terminal block

U :Operating stop voltage

is set at a lower value

Z :with ZT

R

12345

LEP

E-4

Recommended Noise Filter

NAC-06-472

High voltage pulse noise type : NAP series

Low leakage current type : NAM series

*The Noise Filter is recommended

*to connect with several devices.
