1.

PURPOSE

This specification covers the delivery requirements for the display module delivered by EM Microelectronic-

Marin SA.

2.

PRODUCT SPECIFICATIONS

2.1

MODULE REVISION AND ORDERING NUMBER

EM Part Number

Customer Part Number

Remarks

TAT07_R01

TBD

Initial revision

2.2

BASIC SPECIFICATION

ITEM

CHARACTERISTICS

Display technology

OLED monochrome, color yellow

Layout

Dot matrix

LCD Driver

SSD1305Z

Interface

Selectable with BS2 and BS1 signals

LCD Module structure

COG+FPC

Estimated useful life time at

ambient conditions

60 khours operating until half brightness

80 khours storage

2.3

MECHANICAL CHARACTERISTICS

ITEM

CHARACTERISTICS

Dots configuration

128 x 64

Dots dimensions (mm)

0.254 (L) x 0.254 (W)

Dots gap (mm)

0.020

Module size (L x W x T, mm)

40.3 (L) x 63.3 (W) x 2.01 (T)

Panel size

40.3 (L) x 27.3 (W) x2.01 (T)

Diagonal AA size

1.54"

Weight (g)

TBD

2.4

ABSOLUTE MAXIMUM RATINGS

Vss = 0 V, Ambient Temp.= 25 °C

Item

Symbol

Condition

Min

Max

Unit

Power supply voltage

Vdd

25 °C

-0.3

+3.5

V

Supply voltage

Vcc

25 °C

8

16

V

Operating temperature

Topr

---

0

+50

°C

Storage temperature

Tstg

---

-20

+70

°C

Operating & storage humidity

RHoprstg

---

0

85

%RH
