153

POWERBOX

ARTICLE

NUMBER

INPUT

VOLTAGE

VDC

OUTPUT

VOLTAGE

VDC

OUTPUT

CURRENT

mA

INPUT CURRENT

NO LOAD

mA

INPUT CURRENT

FULL LOAD

mA

MAA 02 003

5

5

300

110

620

MAA 02 006

5

12

125

110

550

MAA 02 009

5

15

100

110

550

MAA 02 012

5

±12

±60

110

550

MAA 02 015

5

±15

±50

110

550

MAA 02 018

12

5

300

40

260

MAA 02 021

12

12

125

40

215

MAA 02 024

12

15

100

40

215

MAA 02 027

12

±12

±60

40

215

MAA 02 030

12

±15

±50

40

215

MAA 02 033

24

5

300

20

130

MAA 02 036

24

12

125

20

115

MAA 02 039

24

15

100

20

115

MAA 02 042

24

±12

±60

20

115

MAA 02 045

24

±15

±50

20

115

MAA 02 048

48

5

300

15

65

MAA 02 051

48

12

125

15

60

MAA 02 054

48

15

100

15

60

MAA 02 057

48

±12

±60

15

60

MAA 02 060

48

±15

±50

15

60

MAA 02 Series

1.5

W A TTS

SINGLE

&

DUAL

OUTPUT

DC/DC

INDUSTRIAL

PIN

SINGLE

OUTPUT

DUAL

OUTPUT

1, 24

+V Input

+V Input

2, 23

NC

-V Output

3, 22

NC

Common

10

-V Output

Common

11

+V Output

+V Output

12

-V Input

-V Input

13

-V Input

-V Input

14

+V Output

+V Output

15

-V Output

Common

PIN

SINGLE

OUTPUT

DUAL

OUTPUT

1, 2, 3

+V Input

+V Input

22, 23, 24

-V Input

-V Input

10, 11

NP

Go Output

12

-V Output

-TP

13

+V Output

-V Output

14

NP

NP

15

NP

+V Output

16

NP

+TP

17

+TP

NP

Pin Connection 500VDC

For isolation voltage 3kV add suffix -H to the article number. Ex MAA 02 003H.

NC = No connection with pin.

Pin Connection 3kVDC

Selection Table
